Tadano Mantis 8012

The Tadano Mantis 8012 is a 40-ton capacity telescopic boom crawler crane designed for versatility and rugged terrain. With a full power 3-section boom reaching 90 feet and the capability to pick-and-carry its full load chart through 360°, the 8012 combines exceptional lifting power with off-road maneuverability.

thumbnail of 8012_brochure_en

⬇ DOWNLOADS ⬇

somdn_product_page
yes here
Available Downloads:

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Advertisement

Product Description

The Tadano Mantis 8012 debuted as a high-capacity tele-boom crawler crane capable of lifting 40 tons (36 tonnes) at a 12-foot radius. It is equipped with a full power, 3-section synchronized telescoping boom that extends from 39 feet (11.9 meters) to 90 feet (27.4 meters), utilizing a single hydraulic cylinder with load-holding valves and cable systems for synchronized action. The boom is engineered for strength and flexibility with elevating angles ranging from -1° to 78°, reaching full elevation in 64 seconds and full extension in just over 100 seconds.

To expand operational reach, the 8012 offers optional lattice-type swing-away boom extensions—a 30-foot extension and a 20-foot jib—which together push the maximum tip height to 140 feet (42.7 meters). Both the extension and jib are designed with heavy-duty sheaves and can be offset at 15° or 30°.

The crane rides on hydraulically retractable steel side frames paired with 36-inch three-bar semi-grouser track shoes, ensuring stability and traction across varied terrain. The two-speed track drives, controlled via pilot hydraulics and powered by axial piston motors, allow for a high travel speed of 1.29 mph (4.8 km/h) and an impressive unladen gradeability of 78%. The travel system also supports skid steering and counter-rotation for tight maneuvering.

Powering the 8012 is a Cummins QSB 6.7 diesel engine rated at 260 horsepower (194 kW) at 2100 RPM, meeting current emissions standards and paired with a 130-amp alternator. This engine feeds dual high-pressure axial piston pumps delivering up to 154 gallons per minute at a system pressure of 4,800 psi (330 bar), supporting all crane functions with precise hydraulic control.

For operational safety and efficiency, the 8012 integrates a modern Rated Capacity Limiter system with a full-color LCD screen displaying critical data like boom length, angle, load radius, and track configuration. Additionally, the cab is equipped with rearview cameras and operator aids, and features a climate-controlled environment with a six-way adjustable seat and emergency shutoff via seat and armrest sensors.

Notably, the Tadano Mantis 8012 excels in pick-and-carry operations with full chart capabilities through 360°, and can telescope the boom under load, even with the tracks retracted. Its rugged design with a low center of gravity, compact retractable track width, and optional cold-weather and auger-ready packages make it a dependable performer in a wide range of challenging environments.
