Comansa 16CM260

Easy to assemble thanks to its modular system and lightweight parts, the 16CM260 is one of the most popular cranes in the regions where it is sold, namely: Asia, Oceania, Africa, Middle East and South America.

This model has a maximum reach of 70 metres with jib sections every 5 metres, giving it great versatility in terms of adapting to the different projects it is used for. The two versions offered, with a maximum load of 10 or 12 tonnes, have a jib-end load of 2,150 kg at a maximum radius, plus 10% when the PowerLift system is activated by the crane operator.

Practically all the jib and counter-jib sections are the same ones used by the 16CM185 and 16CM220 models, and its tower sections are also compatible with these models.

Additional Information

Downloads

Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

thumbnail of 16CM260-10_spec_mt_en_vDS201809009
Metric, EN (10 ton)
thumbnail of 16CM260-10_spec_mt_en_vDS201810009
Metric, EN (10 ton)
thumbnail of 16CM260-12_spec_mt_en_vDS201809010
Metric, EN (12 ton)
thumbnail of 16CM260-12_spec_mt_en_vDS201810010
Metric, EN (12 ton)

Product Description
