Sany SAC6000T7-8

The Sany SAC6000T7-8 is an advanced all-terrain crane with impressive capabilities. It features a seven-axle full-ground chassis, equipped with a dual-engine setup. The crane boasts a seven-section U-shaped main boom, extending up to 90.1 meters. Additionally, it comes with a fixed luffing jib that offers multiple combinations of lengths ranging from 12 meters to 60 meters, with variable angles of 0°, 20°, and 40°. The maximum lifting height reaches an impressive 133 meters.

This crane is designed for robust lifting performance, with a unique self-assembly system called the “super-lifting device,” eliminating the need for auxiliary cranes during assembly, effectively doubling the lifting capacity of the longer boom sections. It is well-suited for wind power applications, featuring a specialized 47-meter wind power jib that enables maintenance and operation of wind turbine components up to 100 meters high.

The SAC6000T7-8 exhibits excellent driving capabilities with its innovative seven-axle reinforced chassis structure, providing all-wheel steering and four-wheel drive. It offers various steering and driving modes, ensuring exceptional adaptability while on the move. The crane is equipped with an intelligent multi-mode hydraulic and pneumatic suspension system, allowing real-time monitoring of the vehicle’s posture and adaptive features such as active elevation and variable damping, providing a comfortable and stable driving experience. The powerful drivetrain, supported by a hydraulic torque converter and slow-speed braking, enhances driving safety and smoothness.

With its 505 large tires, the crane can achieve significantly higher transfer speeds, without speed limitations during on-site setup with boom and outrigger deployment. When equipped with the super-lifting device, the transfer speed can reach up to an impressive 60 km/h. These features make the Sany SAC6000T7-8 a highly versatile and capable all-terrain crane, suitable for a wide range of heavy lifting tasks in various industries.

Efficient

– The crane is equipped with a multi-pump, multi-circuit hydraulic system, featuring electronic proportional and multi-stage pressure control, which optimizes speed shifting and micro-movement, resulting in outstanding performance.
– A brand-new fixed length tension control technology enables one-click automatic tensioning and extension/retraction of the superlift, increasing operational efficiency by 20% and enhancing lifting performance by 5% to 10% in the mid-to-long boom sections.
– The crane’s operational restrictions are minimized, and it offers multiple superlift operation modes, three leg span combinations, and three counterweight swing radii, providing comprehensive adaptability to narrow job sites.

Safety

– The crane is equipped with a multifunctional wireless remote control system, making crane operations more convenient and ensuring safer handling.
– It comes with a tilt-over warning system, safety protection procedures, and fault diagnosis system to ensure the crane’s operational safety.
– The crane utilizes a high-precision, highly stable, and intelligent moment limiter system, offering all-around protection for lifting operations.
– The inclusion of various sensors provides real-time data feedback, allowing for continuous monitoring and instant awareness of the crane’s overall working condition.
