Nippon Grove TMS 2000

The Nippon Grove TMS 2000 is a 20-ton hydraulic truck crane featuring a 26-meter boom and up to 12-meter jib extension, offering a total lifting reach of 38 meters. Built on a compact carrier and equipped with synchronized hydraulic boom extension, it is designed for efficient and reliable operation on general construction and utility sites.

Brochure, JA

⬇ DOWNLOADS ⬇

somdn_product_page

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Advertisement

Product Description

The Nippon Grove TMS 2000 is a 20-ton class hydraulic truck-mounted crane built to provide dependable lifting performance in mid-size construction and utility applications. The crane’s main boom extends from 10.1 meters to 26.0 meters using a 3-section, fully synchronized hydraulic extension system. The jib, available in 7.4-meter and 12-meter lengths, can be attached for greater reach and is mounted with a 5° offset. When fully configured, the crane achieves a maximum lifting height of 38.0 meters (26.0-meter boom + 12.0-meter jib).

Its rated lifting capacities include 20.0 tons at 3.0 meters with the 10.1-meter boom, 12.1 tons at 4.5 meters with the 18.1-meter boom, and 7.5 tons at 6.5 meters with the 26.0-meter boom. With the jib installed, the crane can handle 3.5 tons at 9.2 meters (7.4-meter jib) and 2.0 tons at 9.3 meters (12.0-meter jib). The boom elevates from -3° to 80° in about 60 seconds, and extends at a speed of 15.9 meters in 70 seconds.

Hoisting performance is strong for a crane in its class, with both main and auxiliary winches achieving rope speeds up to 87 meters per minute. Slewing is powered by a radial piston hydraulic motor and operates at 3.0 rpm for full 360° rotation. The TMS 2000 is mounted on either the Nissan KW 30M or ZT 300 chassis and has a total vehicle weight of approximately 21,980 kg. The outrigger system spans 5.2 meters and uses a hydraulic lock for stability during lifting.

Control systems include a variety of safety devices such as an electronic moment limiter, overload prevention, boom elevation and extension limiters, holding valves, and winch drum locks. The boom hoist uses a direct-acting hydraulic cylinder with a lock valve, and the winch system incorporates a band brake and automatic drum brake for smooth load handling. The slewing mechanism also includes a reduction gear and internal disk brake for smooth operation.

Overall, the TMS 2000 is a compact and capable crane with well-balanced reach, speed, and safety systems. Its simple, reliable hydraulic layout and efficient transport profile make it suitable for contractors requiring a nimble yet powerful truck crane for daily lifting operations.
