Zoomlion ZTC300V532

The Zoomlion ZTC300V532 is a high-performance 30-ton truck-mounted hydraulic crane, designed to provide strong lifting capacity, efficient mobility, and intelligent operation. The crane features a five-section U-shaped telescopic boom, which extends from 10.7 meters to 42 meters, offering high bending resistance and stability. Additionally, it includes an 8-meter jib with offset angles of 0°, 15°, and 30°, allowing for greater operational flexibility. The maximum lifting height reaches 50 meters, making it ideal for a wide range of lifting applications.

Powered by a WEICHAI WP7.270E31 diesel engine, the ZTC300V532 delivers 199 kW of power and 1,160 N·m of torque, ensuring strong performance in demanding conditions. The FAST mechanical transmission system offers nine forward gears and one reverse gear, providing efficient power delivery and smooth operation. With a maximum driving speed of 90 km/h and a gradeability of 42%, this crane is designed for fast and efficient transport between job sites. The minimum turning diameter of ≤20 meters enhances maneuverability in tight spaces.

For lifting efficiency, the ZTC300V532 is equipped with dual winches, delivering a hoist rope speed of 120 m/min (main and auxiliary winches), ensuring fast and precise lifting. The boom derricking time is 25 seconds, and boom telescoping takes 84 seconds, allowing for rapid setup and operation. The load-sensing slewing system, with a slewing speed of 0-2.7 rpm, ensures smooth rotation and precise load positioning.

The chassis is constructed from high-strength steel, providing robust durability for heavy-duty operations. The suspension system features front leaf springs and a rear pneumatic suspension with stabilizers, ensuring better load distribution and driving stability. The H-type outrigger system provides a fully extended transversal width of 6.2 meters, while an intermediate extension width of 4.25 meters enhances stability during lifting operations.

Operator comfort and safety are key design priorities in the ZTC300V532. The spacious cab is ergonomically designed, featuring climate control (AC and heater), an adjustable seat, and an intuitive control panel for improved visibility and ease of operation. The electrical system (DC 24V) with CAN BUS technology enhances control precision and monitoring capabilities. Safety features include a load moment indicator (LMI), relief valves, hydraulic locks, and emergency stop functions, ensuring secure and stable operation.
