Kato NK-1000

The Kato NK-1000 represents a high-performance 100-ton truck-mounted hydraulic crane that integrates Kato’s signature mechanical precision with advanced hydraulic systems to deliver dependable heavy-lift performance on diverse job sites. Built with a focus on stability, control, and high lifting productivity, the NK-1000 combines an advanced full-power boom system, a unique SL luffing jib, and intelligent load monitoring to support both standard and complex lifting operations.

The crane’s main boom is a 4-section, hydraulically telescoping boom with lengths ranging from 12.0 to 47.5 meters, fabricated using high-strength materials with a rounded box-type cross-section for improved durability and torsional resistance. It features Kato’s full-power boom system, offering smooth and continuous telescoping across all boom stages.

For additional height and outreach, the NK-1000 is equipped with a two-stage hydraulic SL (Super Luffing) jib, available in lengths from 8.4 to 21.0 meters. The jib can be deployed at offset angles of 5° to 45°, and its design enables rapid deployment using hydraulic cylinders and mechanical linkages stored on the boom side. When paired with the main boom, the crane can reach a maximum lifting height of 69.0 meters, making it suitable for high-rise building or utility projects.

The crane’s rated lifting capacity includes:

• 100 t × 3.0 m radius (main boom)
• 12 t at 47.0 m
• 3.8 t at 47.0 m with 4.8 m SL jib
• 2.2 t at 47.0 m with 21.0 m SL jib

The crane’s lifting system utilizes oil-pressure-powered dual planetary gear winches, featuring automatic disc brake systems and multiple speed options. Maximum winch speed is up to 107 m/min under light loads, with controlled slow speeds for delicate hoisting tasks. The main and auxiliary wire ropes are 22 mm in diameter, designed to handle large hook blocks with 100 t (6 sheaves), 40 t (2 sheaves), and 7 t (single sheave) configurations.

Powering the crane’s superstructure is a Nissan NE6T04 diesel engine, outputting 180 PS at 2200 rpm and torque of 69 kg·m at 1500 rpm, with a fuel tank capacity of 300 liters. The oil reservoir holds 107.5 liters, and the hydraulic system includes multi-pump circuits with variable flow regulation, supporting simultaneous operations with precise responsiveness.

The carrier unit is mounted on a 5-axle truck chassis (W-KG520RN), powered by a Nissan V8 diesel engine, producing 340 PS at 2200 rpm, and maximum torque of 120 kg·m at 1200 rpm. The vehicle reaches a maximum speed of 60 km/h, with a minimum turning radius of 9.8 meters. The carrier also features hydraulic suspension, air brakes, and automatic leveling outrigger jacks.

The outrigger system includes three-stage hydraulic extensions with spans of 8.6 m (max), 6.6 m (mid), and 4.8 m (min). Kato’s ACS (Automatic Crane System) is installed as standard, incorporating safety interlocks, load monitoring, boom/jib angle detection, and outrigger extension sensors to prevent overloads and ensure stable operations in real-time.

Other notable features include:

• Free-fall winch clutch disengagement
• Electronically controlled boom swing
• Winch drum rotation indicators
• Compact turning performance (9.8 m radius)
• Cab air-conditioning and radio
• One-touch hydraulic counterweight dismount system

In summary, the Kato NK-1000 offers a powerful and adaptable solution for lifting tasks up to 100 tonnes. With its combination of a robust boom, advanced luffing jib, high-speed winching, and user-friendly safety systems, the NK-1000 is a top-tier choice for contractors requiring efficient and safe heavy-lift performance on mobile truck crane platforms.
