Zoomlion ZTC600R562

The Zoomlion ZTC600R562 is a 60-ton hydraulic truck crane engineered for superior lifting performance, stability, and operational efficiency. Designed to handle demanding construction, infrastructure, and industrial applications, this crane incorporates advanced hydraulic systems, intelligent controls, and a durable chassis to ensure high productivity and reliability.

The crane features a five-section U-shaped main boom that extends from 11.6 meters to 45 meters, utilizing ropes and sheaves for smooth telescoping. Additionally, it comes with a two-section foldable jib with a side layout and bottom opening design, offering adjustable offset angles of 5°, 25°, and 45° for increased versatility. The maximum lifting moment reaches 2,033 kN·m, with a lifting height of 45.7 meters (main boom) and 61.5 meters (with jib), ensuring excellent reach and load-handling capabilities.

To enhance lifting efficiency, the ZTC600R562 is equipped with dual winches powered by variable displacement piston motors and planetary reducers, providing a maximum hoist rope speed of 125 m/min. The load-sensing slewing system with a proportional main valve allows for precise micro-positioning, with a minimum stable slewing speed of 0.1°/s, ensuring accurate load control. The crane’s boom derricking time is 45 seconds, while boom telescoping is completed in 95 seconds, supporting rapid and efficient operation.

The chassis is designed for strength and durability, featuring a high-tensile steel plate construction. The four-axle configuration provides optimal weight distribution, with the front two axles used for steering and the rear two for driving. The powertrain is driven by a WEICHAI WP9H336E62 diesel engine, producing 247 kW of power and 1,600 N·m of torque, paired with a FAST 10-speed mechanical gearbox (10 forward, 2 reverse gears) for smooth and efficient transmission. With a maximum driving speed of 60 km/h and a gradeability of 47%, the crane offers excellent maneuverability, even on challenging terrain. The minimum turning diameter of ≤23 meters further enhances its ability to navigate confined job sites.

For stability, the ZTC600R562 is equipped with H-type outriggers, providing a fully extended outrigger width of 5.92 meters and a longitudinal spread of 7.1 meters. The counterweight system totals 11 tons, including a 5-ton fixed counterweight and two auxiliary counterweights (3.5T and 2.5T), allowing for flexible load adjustments. The suspension system combines a front leaf spring with rear rubber suspension and thrust rod balancing, improving ride comfort and stability.

Operator comfort and safety are key priorities in the ZTC600R562. The newly designed cab offers a spacious, ergonomic layout with a 20° tiltable function, air conditioning, and heating, ensuring a comfortable working environment in all weather conditions. Additionally, the superstructure and chassis electrical systems operate on a DC 24V system, providing reliable power for all functions. Safety features include a Load Moment Indicator (LMI), limit switch, relief valve, emergency stop button, and anti-rollover protections, ensuring safe operation in demanding conditions.

The crane also incorporates energy-efficient features, such as an intelligent multi-power energy-saving system that reduces fuel consumption to below 43 liters per 100 km, resulting in up to 15% fuel savings. The hydraulic system, optimized for smooth and efficient operation, has a tank capacity of 840 liters, supporting extended work periods with minimal downtime.

With its exceptional lifting performance, intelligent control systems, durable chassis, and operator-friendly features, the Zoomlion ZTC600R562 is a top-tier solution for high-demand lifting applications. Its combination of power, precision, efficiency, and comfort makes it an ideal choice for modern construction and infrastructure projects.
