Liebherr 125 K

The 125 K has been specially developed for civil engineering requirements such as road traffic bridges and commercial as well as industrial building construction.

Additional Information

Downloads

Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

thumbnail of 125K_brochure_en
Brochure, EN
thumbnail of 125K_specc_mt_en
Metric, EN

Product Description

Lifting capacity at max. radius 1,300 kg
Max. radius 55.00 m
Standard EN 14439
Max. lifting capacity 8,000 kg
Lines 2
Max. hook height 41.50 m
Luffed jib position 30 °
Jib position to avoid obstacles 45 °
Slewing radius 3.20 m
Hoist gear 18 kW FU
Slewing gear 7,5 kW FU
