Hitachi-Sumitomo SCX900HD

Crawler Crane

The Hitachi-Sumitomo SCX900HD is a 90-ton heavy-duty crawler crane designed for tough lifting applications. It features a maximum boom length of 61 meters and an optional jib length of 13 to 25 meters. Powered by a Mitsubishi 6D24-TL engine delivering 220 kW, the crane offers versatile winch speeds, a swing speed of 3.5 rpm, and a travel speed of 1.5 km/h, making it suitable for demanding construction projects.

Downloads

Available Downloads:

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

The Hitachi-Sumitomo SCX900HD is a robust crawler crane engineered for heavy-duty lifting tasks, with a maximum rated load capacity of 90 tons at a 4-meter working radius. This crane is equipped with a basic boom that starts at 13 meters and extends up to 61 meters for various lifting requirements. Additionally, it supports optional jib lengths ranging from 13 to 25 meters, providing a total boom and jib length of up to 86 meters.

The SCX900HD is powered by a Mitsubishi 6D24-TL diesel engine that produces 220 kW (300 PS) at 2,000 rpm. This engine provides the necessary power for demanding lifting tasks while maintaining fuel efficiency. The crane’s maximum line pull for the winch is 13 tons, with a single-line pull capacity of 25 tons, allowing for heavy-duty operations.

The crane’s winch system features adjustable speeds, with main and auxiliary drum speeds reaching 100 meters per minute in high mode, 57 meters per minute in medium mode, and 28 meters per minute in low mode. The boom hoist operates at a speed of 64 meters per minute, while the optional third hoist drum can achieve similar speeds for enhanced operational flexibility. The crane also has a swing speed of 3.5 rpm, providing smooth and efficient load rotation.

For mobility, the SCX900HD offers a travel speed of 1.5 km/h in high mode and 1.0 km/h in low mode. It has a gradeability of 30%, making it capable of navigating slopes and rough terrains. Ground contact pressure is around 89.5 kPa, ensuring stable operation on various surfaces.

The crane’s operating weight is approximately 88.9 tons, including a 13-meter boom and a 90,000 kg capacity hook, ensuring a stable base for lifting heavy loads. This crane is suitable for heavy construction projects, industrial applications, and infrastructure development, where powerful lifting performance and flexibility are essential.

Overall, the Hitachi-Sumitomo SCX900HD combines strength, versatility, and reliable engine performance, making it ideal for heavy-duty lifting tasks in demanding environments.
