Lampson Transi-lift LTL-350/500

The Lampson LTL-350 Transi-Lift® Mobile Cranes are two models of the world’s most versatile heavy lift system. These models combine heavy-lift capabilities of Ringer® equipped cranes with the mobility of conventional crawler mounted equipment.

Utilizing the patented Transi-Lift® concept, Lampson has teamed a conventional lift crane with a crawler-transporter to dramatically increase the lift capacity while still maintaining excellent mobility.

As an added benefit these models of Transi-Lift can be quickly reconfigured back to conventional lift cranes when the additional heavy lift capacities are no longer required.

Additional Information

Downloads

Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

thumbnail of LTL-350_LTL-500_brochure_en
Brochure, EN

Product Description

  • Max Capacity – Series 2 – 230 U.S. Tons
  • Max Line Pull Main Drum – 55,000 lbs
  • Max Line Pull Aux Drum – 55,000 lbs
  • Maximum Erected Main Boom Length – 260′
  • Maximum Erected Main Boom and Jib Length – 230′  Boom 60′ Jib
  • Max Spooling Capacity  Main Drum – 2,200′ of 1-1/8″ or 1,800′ of 1-1/4″
  • Max Spooling Capacity Aux Drum – 2,200′ of 1-1/8″ or 1,800′ of 1-1/4″
  • Ability to Accept Manitowac Ringer® and Tower® Attachments with No Modifications
  • Tandem Drum Operation for Endless Reeving
  • Meets FedOSHA Requirements for Man Basket Suspension – No Freefall Capability
