Zoomlion ZCC5000

The Zoomlion ZCC5000 crawler crane is engineered with an emphasis on stability and efficiency. It possesses an impressive maximum lifting moment of 390 t.m and can handle a rated load of 12 t with a single line in fixed jib mode. This crane’s total weight approximates 85.2 tons, signaling its substantial build and capability.

Engine and Hydraulic System

Equipped with a WEICHAI WP12GZ70E301 engine, the ZCC5000 ensures a potent performance with a rated power of 199 kW at 2000 rpm. Its maximum output torque reaches 1200 N.m, supporting demanding tasks with ease. The hydraulic system, integral to its operations, is a series-connected setup with hydraulic pilot proportional control, showcasing high efficiency and allowing for smooth simultaneous movements.

Hoisting and Derricking Winch

The crane’s main and auxiliary hoisting winches, powered by an axial piston variable displacement motor, support line pulls of up to 120 kN, with a maximum rope length of 200m for the main winch. For the derricking winch, sophisticated design ensures precise control over boom angle adjustments.

Slewing and Traveling Mechanisms

The slewing system operates smoothly at 0-2.4 rpm, courtesy of an axial piston constant displacement motor and planet reducer. The crawler crane’s traveling mechanism is driven by each hydraulic driving system’s hydraulic motor, allowing for efficient maneuvering of the crane on-site with a travel speed of up to 1.3 km/h.

Innovative Features and Safety Devices

Zoomlion’s commitment to innovation is evident in the ZCC5000’s design. It incorporates advanced safety devices and offers high work efficiency. The crawler chassis’s large gauge track guarantees comprehensive stability, allowing for the execution of complex lifts with precision and security.

Lifting Performance

The ZCC5000 shines in its lifting performance, capable of executing challenging lifts with its substantial load moment and capacity. Its boom configurations and overall dimensions speak to its capability to adapt to various project requirements, making it an essential asset for large-scale industrial and construction projects.

With its considerable contributions to the lifting industry, the Zoomlion ZCC5000 stands as a monument of Zoomlion’s dedication to heavy-lifting technology and customer satisfaction.
