Kobelco SL 13000

Crawler Crane

The Kobelco SL13000 is an 800-ton crawler crane, designed for heavy lifting in large-scale construction, infrastructure, and energy projects. It features a maximum main boom length of 135 meters (443 feet) and a luffing jib system extending the total height to 186 meters (610 feet). Developed as an upgraded version of the Kobelco 7800, the SL13000 was introduced in 1993 with an expanded counterweight chassis and attachments. It became one of the largest crawler cranes in Japan at the time and was adopted by major crane rental companies, including Uchimiya and Kitashikoku. With advanced hydraulic control, high lifting precision, and excellent stability, the SL13000 remains a powerful and reliable crane for demanding lifting applications.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

The Kobelco SL13000 was introduced in 1993 as an upgraded version of the Kobelco 7800, which had a maximum lifting capacity of 750 tons. By expanding the counterweight chassis and attachments, Kobelco successfully increased the crane’s lifting capacity to 800 tons, making it one of the largest crawler cranes in Japan at the time. The crane was quickly adopted by leading Japanese crane rental companies, such as Uchimiya and Kitashikoku, due to its exceptional performance in high-capacity lifting applications.

The SL13000 features a maximum main boom length of 135 meters (443 feet), providing a wide working radius and significant lifting reach. When equipped with a luffing jib, the total system height extends to 186 meters (610 feet), making it ideal for ultra-high lifting operations in offshore wind power, industrial plants, and large infrastructure projects. Its crawler undercarriage is designed for superior ground adaptability, ensuring stability even on soft or uneven terrain.

Powered by a high-output diesel engine, the SL13000 delivers efficient fuel consumption and strong torque output, optimizing lifting efficiency for heavy loads. The hydraulic high-pressure system allows for precise boom control, smooth load handling, and fast lifting cycles. The slewing system offers full 360-degree continuous rotation, improving load positioning flexibility.

For safety and operational precision, the SL13000 is equipped with Kobelco’s Automatic Moment Limiter (AML), anti-two-block protection, and real-time stability monitoring sensors. The hydraulic self-assembly system enables quick and easy setup, reducing downtime and increasing project efficiency. The modular counterweight system allows for adjustable configurations, ensuring stability across various lifting scenarios.

The operator’s cab is ergonomically designed for maximum comfort and control, featuring digital load monitoring displays, joystick controls, and climate control systems. These features help improve operator efficiency and reduce fatigue during long working hours.

With its strong lifting capacity, high adaptability, and advanced hydraulic control systems, the Kobelco SL13000 remains a leading choice for heavy-lifting operations, proving reliability, efficiency, and stability in complex construction and industrial environments.
