Zoomlion ZCT1000V532

The Zoomlion ZCT1000V532 is a versatile 100-ton telescopic crawler crane with a substantial lifting moment of 352 ton-meters, designed for a variety of applications. The crane boasts a telescopic main boom length that ranges from 12.7 meters to an impressive 50 meters, complemented by a jib extendable from 9.5 to 16 meters. This allows for a combined maximum length of 66 meters when using the main boom with the fixed jib. The main boom can be positioned within a wide angle range of -1 to 80 degrees, and the jib angle settings include 0, 15, and 30 degrees. The crane achieves a maximum single rope speed of 142 meters per minute on both the main and auxiliary hoisting winches, ensuring swift and efficient lifting operations.

With a quick boom derricking up time of 65 seconds and a slewing speed of 0 to 1.6 rpm, the ZCT1000V532 enhances job site productivity. Its traveling speed tops out at 2 km/h, which, along with a notable gradeability of 45%, underscores the crane’s adeptness in maneuvering across various terrains. Ground pressure is kept to a minimum at 0.1 MPa, emphasizing its suitability for sensitive surfaces.

Regarding its dimensions and transportability, the crane maintains a deadweight of 90 tons with the main hook installed and carries a counterweight of 32 tons. The overall dimensions are considerable at 15,410 x 5,270(3,490) x 3,375 mm, ensuring stability and support during lifting tasks. The engine, a Weichai WP6G220E301 model, delivers a rated power of 199 kW at 2,000 rpm and a maximum output torque of 1,200 Nm at 1,500 rpm, adhering to the Chinese National Stage III exhaust emission standards. The crane’s noise levels are maintained at ≤107 dB outside the operator’s cab and ≤85 dB inside, balancing operational demands with environmental considerations. The distance between track centers and crawler contact length and width varies between retracted (2,690 x 5,530 x 800 mm) and extended (4,470 x 5,530 x 800 mm) crawler states, which accommodates transportation and operational needs. The ZCT1000V532’s blend of power, precision, and versatility makes it an asset for challenging construction and lifting projects.
