Tadano Mantis 10010Mx

The Tadano Mantis 10010Mx is a 50-ton class tele-boom crawler crane equipped with a 4-section full-power boom that extends from 37’6″ to 111’6″ (11.4 to 34 m). With its pick-and-carry capabilities, powerful winch systems, and retractable tracks, it is ideal for confined or rugged job sites in construction, utility, and petrochemical applications.

thumbnail of 10010Mx_brochure_en

⬇ DOWNLOADS ⬇

somdn_product_page
yes here
Available Downloads:

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Advertisement

Product Description

The Mantis 10010Mx offers a maximum lifting capacity of 50 US tons at 10 ft radius, making it highly effective for medium-lift applications. The 4-section full-power synchronized boom uses dual hydraulic cylinders with load-holding valves and telescopes from 37’6” to 111’6” (11.4 – 34 m) in just 102 seconds. Optional boom extensions include a 30 ft swing-away extension and a 20 ft jib, allowing a maximum tip height of 162 ft (49.4 m).

The crane is powered by a Cummins QSB 6.7 diesel engine, delivering 260 hp (194 kW) at 2,100 rpm. Hydraulic output reaches 154 gpm at 4,800 psi, feeding the crane’s winches, travel system, and boom functions. Both main and auxiliary winches are planetary geared with two-speed bent axis hydraulic motors, offering:

  • Main winch: 15,530 lb line pull, 230 ft/min speed
  • Auxiliary winch: 12,000 lb line pull, 217 ft/min speed

The fully enclosed, air-conditioned cab includes an adjustable seat, full instrumentation, and safety aids like seat/armrest cutoff switches and rear cameras. The Rated Capacity Limiter (RCL) continuously monitors load, boom angle, tip height, radius, and parts-of-line, while the anti-two block system provides automatic function cut-off with audible and visual alerts.

Travel performance is strong, with independent hydrostatic drives offering 0.78–1.29 mph speeds and 57% gradeability. The track frames extend/retract hydraulically, and the crane offers multiple track shoe options including 24″, 30″, and 36″ widths. Depending on configuration, operating weight ranges from 99,690 lb to 103,640 lb, with ground pressure as low as 7.4 psi.

Optional features include:

  • Tool circuit (5 or 10 gpm @ 2,500 psi)
  • Auger-ready and complete auger packages
  • Free-fall winches
  • Cold weather kits for -40°C operation
  • Pole claw and WP750 work platform
  • Radio remote control

With 360° pick-and-carry capability, fast setup, and strong mobility even with retracted tracks, the Mantis 10010Mx is a dependable solution for applications that demand strength, flexibility, and operational efficiency.
