Sany Palfinger SPS 25000
Sany Palfinger SPS 25000 is a 25 mt rated capacity truck mounted crane.
Downloads
*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.
Related Models
Advertisement
Product Description
Basic Data | SPS 25000B | SPS 25000C |
---|---|---|
Rated Lifting Moment | 25 mt | 25 mt |
Rated Lifting Capacity | 10000 kg (2.5m) | 10000 kg (2.5m) |
Max. outreach | 14.0 m | 17.7 m |
Max. lines of the hook | 6 | 6 |
Slewing angle | Continuous | Continuous |
Boom raising angle | 0 ~ 75° | 0 ~ 75 ° |
Max. lifting height (the measurement from the ground after the outriggers are fully extended) | 16.1 m | 20.1 m |
Length of the boom system (retracted) | 5.3 m | 5.3 m |
Length of the boom system (fully extended) | 14.3 m | 18.1 m |
Boom sections | 4 | 5 |
Outrigger span (fully extended) | 5600 (mm) | 5600 (mm) |
Recommended flow rate | 60 – 90 L/min | 60 – 90 L/min |
Operating pressure | 31 Mpa | 31 Mpa |
Recommended oil tank capacity | 200 L | 200 L |
Crane moment (dynamic) | 416.0 kNm 42.4 mt |
433.7 kNm 44.2 mt |
Torsional moment (dynamic) | 26.3 kNm 2.7 mt |
26.3 kNm 2.7 mt |
Crane Weight | 3820 kg (Floor Control) 3850 kg (High Seat) |
4110 kg (Floor Control) 4130 kg (High Seat) |
