Sany Palfinger SPS 35000
Sany Palfinger SPS 35000 is a 35 mt rated capacity truck mounted crane.
Downloads
*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.
Related Models
Advertisement
Product Description
Basic Data | SPS 35000B | SPS 35000C |
---|---|---|
Rated Lifting Moment | 35 mt | 35 mt |
Rated Lifting Capacity | 14000 kg (2.5m) | 14000 kg (2.5m) |
Max. outreach | 15.0 m | 18.1 m |
Max. lines of the hook | 6 | 6 |
Slewing angle | Continuous | Continuous |
Boom raising angle | 0 ~ 75° | 0 ~ 75 ° |
Max. lifting height (the measurement from the ground after the outriggers fully extended) | 17.1 m | 20.5 m |
Length of the boom system (retracted) | 5.4 m | 5.6 m |
Length of the boom system (fully extended) | 15.4 m | 18.5 m |
Boom sections | 4 | 5 |
Outrigger span (fully extended) | 6000 (mm) | 7250 (mm) |
Recommended flow rate | 60 – 90 L/min | 60 – 90 L/min |
Operating pressure | 32 Mpa | 32 Mpa |
Recommended oil tank capacity | 200 L | 200 L |
Crane moment (dynamic) | 577.2 kNm 58.8 mt |
577.2 kNm 58.8 mt |
Torsional moment (dynamic) | 36.8 kNm 3.8 mt |
36.8 kNm 3.8 mt |
Crane Weight | 4400 kg (Floor Control) 4550 kg (High Seat) |
6000 kg (Floor Control) 6120 kg (High Seat) |
