Sany Palfinger SPS 30000

Sany Palfinger SPS 30000 is a 30 mt rated capacity truck mounted crane.

Additional Information

Max. Rated Capacity

SI-unit

Metric Ton

Downloads

thumbnail of SPS30000_spec_mt_ch
SPS 30000 | Metric | CH

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Predecessor/Successor Models

Photo Gallery

Product Description

Basic Data SPS 30000B SPS 30000C
Rated Lifting Moment 30 mt 30 mt
Rated Lifting Capacity 12000 kg (2.5m) 12000 kg (2.5m)
Max. outreach 14.5 m 18.1 m
Max. lines of the hook 6 6
Slewing angle Continuous Continuous
Boom raising angle 0 ~ 75° 0 ~ 75 °
Max. lifting height (the measurement from the ground after the outriggers are fully extended) 16.5 m 20.5 m
Length of the boom system (retracted) 5.4 m 5.6 m
Length of the boom system (fully extended) 14.8 m 18.5 m
Boom sections 4 5
Outrigger span (fully extended) 6000 (mm) 6000 (mm)
Recommended flow rate 60 – 90 L/min 60 – 90 L/min
Operating pressure 30 Mpa 30 Mpa
Recommended oil tank capacity 200 L 200 L
Crane moment (dynamic) 507.3 kNm
51.7 mt		 507.3 kNm
51.7 mt
Torsional moment (dynamic) 30.0 kNm
3.1 mt		 30.0 kNm
3.1 mt
Crane Weight 4200 kg (Floor Control)
4200 kg (High Seat)		 4650 kg (Floor Control)
4650 kg (High Seat)
