Unic UR-V370 Series

Unic UR-V370 series is a light-duty truck-mounted crane that has a 3.03-tonne rated capacity and a maximum hook height between 9.2m to 15.9m.

Additional Information

Downloads

Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

thumbnail of UR-V370_catalog_en
UR-V370 Series | EN

Product Description

MODEL UR-V373 UR-V374 UR-V375 UR-V376
Max. Lifting Capacity 3,030 kg at 2.7 m 3,030 kg at 2.6 m 3,030 kg at 2.4 m 3,030 kg at 2.4 m
Max. Hook Height 9.2 m 11.4 m 13.7 m 15.9 m
Max. Working Radius 7.51 m 9.81 m 12.11 m 14.42 m
Max. Boom Length 7.70 m 10.00 m 12.30 m 14.61 m
Min. Boom Length 3.31 m 3.41 m 3.54 m 3.63 m
Boom Sections 3 4 5 6
Boom Raising Angle Min. 1° to Max. 78°
Slewing Angle 360° Continuous
