Tadano ATF50G-3

The ATF50G-3 was introduced to the world during 2007 Bauma show held in Munich, Germany which another five brand new models was also being released. The 50 tonnes all terrain crane was a replacement for ATF45-3 all-terrain crane with better specifications.

The boom length has been increased to 40 meters while it comes with two boom extension cylinders with ropes to give a maximum setup speed. The crane can be fitted with the optional 16 meters bi-fold jib extension which is easy to handle, a feature that was seen on ATF65G-4 all-terrain crane. There is a taxi version of the counterweight which is 7 tonnes and maximum counterweight of up to 10 tonnes. AML is standard equipment.

Categories:

Additional Information

Downloads

Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

thumbnail of ATF50G-3_spec_lb_en
Imperial, EN
thumbnail of ATF50G-3_spec_mt_en_v2013
Metric, EN
thumbnail of ATF50G-3 spec mt en v2013
Metric, EN
