Liebherr LTM 1350-6.1

Mobile Crane

The Liebherr LTM 1350-6.1 is a 350-ton all-terrain crane, designed for high-performance lifting in construction, infrastructure, and industrial projects. It features a 70-meter (229.7-foot) telescopic main boom, which surpasses its predecessor, the LTM 1300-6.1, by an additional 10 meters. With a maximum system height of 152 meters (498.7 feet) when equipped with a lattice jib, this six-axle crane is recognized as the strongest in its class. First introduced at CONEXPO-CON/AGG 2011, the LTM 1350-6.1 is powered by a Liebherr 8-cylinder turbo-diesel engine (450 kW) in the carrier and a 4-cylinder turbo-diesel engine (180 kW) in the superstructure, ensuring efficient operation and outstanding lifting capabilities.

⬇ DOWNLOADS ⬇

Available Downloads:

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Product Description

The Liebherr LTM 1350-6.1 is an advanced 350-ton all-terrain crane, engineered to deliver superior lifting performance, reach, and maneuverability in demanding job site environments. First unveiled at CONEXPO-CON/AGG 2011, this model introduced a longer 70-meter (229.7-foot) main boom, surpassing the LTM 1300-6.1 by 10 meters. This upgrade, combined with its maximum 78-meter (255.9-foot) lattice jib, allows the crane to achieve a maximum system height of 152 meters (498.7 feet), making it ideal for high-elevation lifting applications.

The LTM 1350-6.1 is widely regarded as the strongest six-axle all-terrain crane in the market, thanks to its optimized load chart and reinforced structure. The boom system is fully hydraulic, enabling fast and smooth telescoping, while the Y-guying system (Y-frame support) enhances stability and lifting capacity when handling heavy loads at greater heights. The crane’s maximum counterweight of 140 tons ensures balanced load distribution, allowing for exceptional lifting performance across various working configurations.

For mobility and efficiency, the LTM 1350-6.1 is built on a six-axle carrier chassis, offering excellent roadability and maneuverability. It is powered by a Liebherr 8-cylinder turbo-diesel engine, delivering 450 kW (603 hp), ensuring strong on-road performance. The superstructure is independently powered by a 4-cylinder Liebherr turbo-diesel engine (180 kW / 241 hp), allowing for efficient crane operation without relying on the carrier’s engine.

The crane is equipped with Liebherr’s LICCON (Liebherr Computed Control) system, providing real-time load monitoring, automatic safety functions, and precise crane operation assistance. The hydro-pneumatic suspension system and all-wheel steering enable tight-radius turning and smooth travel on highways and rough terrains. Additionally, the outrigger system offers multiple extension positions, optimizing lifting stability on various ground conditions.

Inside the operator’s cab, the LTM 1350-6.1 features an ergonomic design, climate control, touchscreen controls, and intuitive joystick operation, ensuring comfort and efficiency during long lifting operations.

With its long boom, powerful lifting capabilities, compact six-axle design, and advanced control systems, the Liebherr LTM 1350-6.1 is an industry-leading all-terrain crane, offering superior reach, strength, and operational efficiency for demanding construction and industrial lifting projects.
