Kobelco TK750G
The TK750G / TK750GFS (hereinafter referred to as TK750G), which went on sale in June 2017, is a new model of the TK series that has been highly evaluated for its success in hard work in harsh field environments centred on foundation civil engineering. .. It is an epoch-making new model that newly meets the industry’s long-awaited condition of “transportation width of less than 3 m” while maintaining the conventional attractiveness such as robust structure, workability, and high lifting ability.
Additional Information
| Max. Rated Capacity | |
|---|---|
| SI-unit | Metric Ton |
Downloads
*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.
Predecessor/Successor Models
Photo Gallery
Product Description
| Maximum Rated Lifting Capacity t × m | 75 × 3.0 | |
|---|---|---|
| Boom Length m | 10.0 ～ 30.1 | |
| Rope Speed | Main Winch m/min | *120 |
| Auxiliary Winch m/min | *120 | |
| Third Winch m/min | *120 | |
| Swing Speed min-1 {rpm} | 2.5 {2.5} | |
| Travelling Speed km/h | High Speed 1.7 / Low Speed 1.2 | |
| Operating Weight (Standard)t | 70.6 | |
| Ground Pressure (Standard)kPa {kgf/cm2} | 83.9 {0.86} | |
| Grade-ability %(degree) | 40(21.8) | |
Engine
| Name | Daimler OM936LA（MTU 6R1000）Diesel Engine |
|---|---|
| Rated Output kW/min-1 | 254 / 2,000 {345 / 2,000} |
Wire Rope
| Main Winch mm | Φ 22 |
|---|---|
| Auxiliary Winch mm | Φ 22 |
| Third Winch mm | Φ 22 |
