Crawler Crane

Zoomlion ZCC100H

The Zoomlion ZCC100H is a robust 100-ton capacity crawler crane engineered for significant lifting tasks. With an operational weight of approximately 85.2 metric tons, this powerful crane is designed to provide stability and precision in challenging environments. It is ideal for large-scale construction projects, boasting a maximum main boom length of 64 meters, a fixed jib length of up to 19 meters, and a lifting moment of 390 t.m, which eclipses the capabilities of many competitors.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

Operating Weight and Equipment

Structure: The ZCC100H includes the basic machine with crawlers, two main winches, wire ropes (200m and 150m), and a 13m main boom composed of FA-frame, boom foot (6.5m), boom head (6.5m), and counterweights totaling 32 metric tons including a 100t hook block.
Total Weight: The crane has an operating weight of approximately 85.2 metric tons, providing a stable lifting platform for various operations.

Performance Capabilities

Lifting Performance: The crane’s large gauge track crawler chassis ensures stability over a 360-degree working range, with a maximum load moment of 390 t.m. The maximum rated load in fixed jib mode is 12 tons (single line), making it more capable than many 100-ton class competitors.
Efficiency: It boasts simultaneous movement capabilities without deceleration when switching between crane functions. The hoisting winch offers a single rope speed of 141m/min and includes a free-fall function for additional operational versatility.

Transportation and Assembly

Transport Optimization: The ZCC100H features a self-erecting A-frame that can be assembled rapidly without an oil cylinder, enhancing job site efficiency. The modular counterweight system allows for easy assembly and disassembly, providing logistical and operational benefits.
Crawler Flexibility: The crawler carriers can be extended or retracted to suit different job site requirements, with a maximum transport width of 3.0 meters.

Technical Specifications

Engine: The crane is powered by a WEICHAI WP7G270E301 engine, producing 199 kW at 2000 rpm and complying with China’s National 3 Emission Standards.
Hydraulic System: The ZCC100H utilizes a series-connected hydraulic system with high-speed motors and pilot proportional control, ensuring smooth and safe simultaneous movements.

Crane Operation and Control

Hoisting and Boom: The crane has both a main and auxiliary winch, with the main winch capable of handling up to 120 kN. The boom winch and swing system, integrated with constant displacement motors, allow for precise control over lifting and slewing operations.
Undercarriage: The undercarriage’s dual crawler system with independent hydraulic drive supports complex maneuvers and efficient site travel.

In conclusion, the Zoomlion ZCC100H crawler crane represents a pinnacle of construction machinery, combining exceptional lifting performance with cutting-edge technology and operational efficiency. Its design and capabilities make it a valuable asset for any construction project requiring high-capacity lifting solutions.
