Raimondi MRT223

The MRT223 is one of the most successful cranes in the history of Raimondi in terms of the number of cranes sold and of customer feedback.

thumbnail of MRT223_spec_mt_en_v2016

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Advertisement

Product Description

Equipped with a 70 meter jib, the MRT223 is an easily-transported Raimondi flattop tower crane with a maximum capacity of 12 tonnes and a maximum tip load of 1.7 tonnes. The crane’s specifications include eight different jib length configurations – ranging from 70 meters to 33 meters – paired with four different hoist winches available at different load capacities and powers ranging from 60hp (45kW) to 100hp (75kW). The MRT223 may be installed on a plinth or on a fixed/travelling cross base, and has been made available in two versatile models: the city version with a 1.7 meter mast section and a maximum freestanding height of 43.6 meters, and the climbing version with a 2.1 meter mast section and a maximum freestanding height of 61 meters. The extreme flexibility of the MRT223 allows it to meets the needs of a wide variety of customers. The MRT223 is well-purposed for both tall buildings, at more than 220 meters in height, as well as residential or commercial buildings at average heights of approximately 35 meters or less.

*This model is no longer in production.
