Ivanovets KC-35714

Truck-Mounted Crane

The Ivanovets KC-35714 is a robust 16-ton truck-mounted crane, designed to handle a variety of construction, assembly, and loading operations. Mounted on the URAL-5557 chassis with a 6×6 wheel configuration, it features a three-section telescopic boom that extends up to 18 meters. This crane is equipped to manage both regular and potentially hazardous loads, making it versatile for different industrial applications.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

The KC-35714 offers a maximum lifting capacity of 16 tons. It’s specifically crafted to operate efficiently with regular loads and can also handle hazardous materials, although the specific capacity for such materials is not detailed in the document and might be different.

Chassis and Mobility

Chassis: The URAL-5557 chassis, adhering to Euro 5 emission standards, provides a sturdy base with a 6×6 axle configuration. This setup enhances the crane’s off-road capabilities and stability, making it suitable for a variety of terrains.
Engine: Powered by a YMZ-53623-10 engine, which delivers 201 kW (273 horsepower), ensuring sufficient power for crane operations and transportation.

Boom and Jib Configuration

Boom Length: The boom extends from 8.0 meters to 18.0 meters, allowing for a significant range of operation. The boom is telescopic, operated by a hydraulic cylinder and a block-and-tackle system for smooth extension and retraction.
Jib Option: A 7.0-meter jib can be added to extend the maximum lifting height to 25 meters, providing additional versatility for higher or more distant lifts.

Safety and Control Systems

Lifting Limiter: Equipped with a microprocessor-controlled lifting limiter that includes a digital display and a built-in data recorder. This system enhances safety by monitoring and regulating load and operation parameters, ensuring compliance with safety standards.

Operational Specifications

Lifting Speed: Offers a range of lifting speeds from 0.2 to 7.5 meters per minute, with a maximum speed for hook lifting at 35.0 meters per minute.
Slewing Speed: Rotates at a rate of 0.3 to 2.5 rotations per minute, providing efficient maneuvering.
Travel Speed: Capable of reaching travel speeds up to 60 km/h, facilitating quick relocation between sites.

Physical Dimensions and Weight

Dimensions: The crane has a transport length of 10,000 mm, a width of 2,500 mm, and a height of 3,520 mm.
Weight: The equipped mass with the main boom is 18.35 tons, which slightly increases to 18.75 tons with the jib attached.

Overall, the Ivanovets KC-35714 is engineered for durability and versatility, capable of meeting the demands of various construction environments with its advanced lifting capabilities and safety features.
