Tadano GA-1500N

The GA-1500N represents one of Tadano’s most capable entries in the heavy all-terrain crane segment. With a rated lifting capacity of 150 metric tons, it is designed for critical applications such as bridge construction, refinery maintenance, large-scale structural steel erection, and wind turbine installation. Its capacity and mobility combine to allow rapid jobsite transitions and efficient setup, enhancing productivity across varied terrain.

The crane is mounted on a 6-axle all-terrain carrier, which provides superior weight distribution and axle load compliance for both domestic and international road regulations. The carrier integrates full-time multiple axle steering, suspension systems, and hydro-pneumatic shock absorption, giving it the ability to navigate congested city streets and uneven jobsite surfaces with confidence. Its maximum road travel speed of 85 km/h makes it highly mobile between job sites without the need for special permits in many jurisdictions.

At the core of the lifting performance is a fully hydraulic, 5-section main boom that extends up to 52 meters. The boom structure is constructed using high-tensile steel and designed with advanced finite element analysis for maximum strength-to-weight ratio. Tadano’s hydraulic telescoping mechanism ensures smooth and efficient boom extension, while optional jib extensions provide additional reach for complex operations, increasing the total lifting height up to approximately 70 meters when configured.

The crane’s superstructure is driven by a dedicated Mercedes-Benz OM502LA engine, delivering substantial power and torque with Stage IIIA emissions compliance. This ensures strong off-road performance while keeping operational emissions in check for environmentally sensitive sites. Hydraulic functions are governed by high-efficiency load-sensing valves and precision electro-hydraulic controllers, allowing fine load positioning and simultaneous multi-function control.

Operator efficiency and safety are central to the GA-1500N’s design. The spacious, tiltable operator cabin offers an unobstructed line of sight, enhanced by a full set of cameras and sensors. Inside, Tadano’s AML (Automatic Moment Limiter) system provides real-time data on load weight, radius, boom angle, and stability margins, with automatic override protection. The ergonomic joystick controls, color touch-screen interface, and integrated work area limitation system help operators manage complex lifts with precision and security.

The crane also features advanced outrigger monitoring, automatic levelling, and programmable lift parameters based on site conditions. For transport logistics, the crane’s counterweights are modular and easily removable, allowing for fast disassembly and compliance with transport restrictions. Setup and teardown times are minimized through hydraulic outriggers and quick-attach systems.

In summary, the Tadano GA-1500N delivers exceptional lifting capability in a mobile, technologically advanced platform. Its blend of strength, smart control, and terrain adaptability makes it an indispensable tool for contractors requiring a high-performing crane with reliable support and proven engineering pedigree.
