XCMG XCA200L8

Mobile Crane

The XCMG XCA200L8 represents a significant leap in all-terrain mobile crane capabilities, offering an extraordinary lifting power of 200 tons complemented by an industry-leading 88-meter main boom. This crane also features a 20-meter secondary boom that can be optionally extended to 36 meters. With a configuration that allows for an impressive 115-meter maximum combined boom length, the XCA200L8 can tackle complex lifting tasks with ease, making it a versatile choice for a wide range of heavy-lifting applications.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

Dimensions and Capabilities

Overall Dimensions (L×W×H): 16230×3000×4000 mm
Total Weight: 54000 kg
Maximum Lifting Capacity: 200 tons
Main Boom Length: 88 meters, the longest in its class, with additional boom configurations available to reach a combined length of up to 115 meters.
Secondary Boom Length: Standard at 20 meters with an optional extension up to 36 meters. (Fixed jib can be common use with XCA180L8)
Installation Angles: Available at 0°, 20°, and 40° for flexible lifting operations.

Power and Performance

Engine Options: Dual-engine configuration with a substantial 405 kW power output from the main engine, providing robust performance.
Gradeability: A powerful 65%, enabling the crane to climb steep gradients with ease.
Ground Clearance: At 307 mm, the crane offers excellent clearance for off-road conditions.
Maximum Lifting Moment: The base boom can achieve a maximum lifting moment of 672 ton-meters, ensuring powerful lifts even at substantial lengths.

Design Features

Turning Radius: A minimal 9.25-meter turning radius allows for superior maneuverability in confined spaces.
Suspension: All axles are equipped with an oil-gas suspension system, ensuring smooth travel and operation.
Operator Cabin: Equipped with the luxurious XCMG G1 dual-cabin design, an integrated dashboard, a 10.4-inch color touchscreen, and electrically heated seats for enhanced comfort.
Control and Visibility: Intelligent boom head lighting for improved night visibility and a multi-functional steering wheel for a car-like user interface, ensuring all operations are within easy reach.

Additional Highlights

Tire Pressure Monitoring: Real-time monitoring for optimal performance and safety.
Intelligent Aids: LED high and low beam lights, a central control lock system for the cabin, and a multi-functional seat designed for optimal ergonomics and control.

The XCMG XCA200L8 stands out as a pinnacle of mobile crane engineering, combining formidable lifting capabilities with advanced technology and operator comfort. Its capacity to handle both the needs for extensive reach and high-lift operations, along with its user-focused design, make it a premier choice in the 200-ton all-terrain crane segment.
