Sany SCC1350HD

The Sany SCC1350HD crawler crane offers a robust lifting capacity of 135 tons, making it suitable for challenging construction projects and heavy lifting tasks. It features a maximum rated lifting moment of 667.8 t·m, ensuring reliable performance across various lifting scenarios. The crane’s main boom can extend from 16 to 61 meters, with a boom luffing angle range of 30° to 80°, providing flexibility for different lifting requirements.

The crane’s operating speeds are optimized for efficient performance. It achieves a main and auxiliary hoist line speed of up to 120 m/min, while the boom hoist speed reaches 80 m/min. The crane’s slewing speed is 1.2 rpm, and it can travel at a maximum speed of 1.3 km/h. The crane is designed to handle heavy-duty operations, with a wire rope diameter of 30 mm and a rated single line pull of 133 kN (approximately 13.5 tons).

Powered by a WP10G336E344 engine, the SCC1350HD delivers an output of 247 kW at 1900 rpm, ensuring sufficient power for demanding lifting tasks. The crane’s overall weight configuration includes a base machine weight of 112,800 kg, with rear counterweights of up to 55,300 kg, allowing for stable operations even under maximum load conditions.

Transport dimensions vary based on configuration, with the main transport dimensions measuring 15.92 x 3.33 x 3.43 meters. The crane’s average ground pressure is between 0.09 MPa and 0.128 MPa, supporting stability across different terrains. It also boasts a gradeability of 30%, making it suitable for use on inclined surfaces.

This model is well-suited for infrastructure projects, industrial applications, and heavy construction, offering reliable lifting capacity and operational flexibility in challenging environments.
