Sany SCC1500A-1 Load Chart PDF + Specifications

The SANY SCC1500A-1 is a 150-ton capacity crawler crane developed for robust lifting performance, versatile configurations, and efficient onsite assembly. It is engineered for construction, infrastructure, and industrial lifting applications where lifting power and setup efficiency are essential. The model represents SANY’s proven lattice boom crawler crane technology tailored for mid-heavy class operations.

The crane’s main boom spans from 15.2 to 76.2 meters, utilizing modular lattice sections for flexibility across site requirements. It supports a fixed jib up to 22 meters, or boom+jib combinations reaching 61.0+24.2 meters, allowing a total lifting height of over 85 meters. This makes the SCC1500A-1 a strong choice for projects requiring both reach and mid-heavy lift capacity, such as bridge segments, plant modules, and wind turbine components.

It delivers a maximum rated lifting capacity of 150 tons at a 4.6-meter radius, with a maximum lifting moment of 850 t·m. The crane features a reliable and efficient Cummins QSL9 diesel engine, delivering 242 kW at 2,100 rpm. This electronically controlled, turbocharged, water-cooled engine meets Tier 3 emission standards, balancing power and environmental compliance.

The hydraulic system is fully load-sensing, enabling smooth and responsive operations across lifting, luffing, slewing, and traveling functions. Its dual main and auxiliary winches deliver rope speeds up to 120 m/min, supporting efficient lifting of long-reach loads. The slewing mechanism offers 360° continuous rotation at speeds up to 2.0 rpm, allowing for precise placement of loads on complex sites.

The SCC1500A-1 uses wide 1000 mm crawler tracks, ensuring excellent ground pressure distribution and jobsite stability. It can travel under its own power at up to 1.3 km/h, with a 30% gradeability, offering practical mobility on moderate slopes or uneven job sites.

For transport and assembly, the crane is modularized with the heaviest single transport unit under 45 tons, making it road-friendly and easier to mobilize across job sites. Self-assembly features, such as hydraulic jacks and boom-raising devices, reduce the need for auxiliary cranes and cut down setup time.

The operator’s cab is ergonomically designed with wide visibility windows, adjustable seating, HVAC, and a digital control interface. It includes a comprehensive Load Moment Indicator (LMI) system, anti-two-block protection, and real-time monitoring of crane parameters for operational safety and efficiency.

In summary, the SANY SCC1500A-1 is a well-balanced 150-ton crawler crane that combines lifting strength, configuration flexibility, and efficient transport design. Its modern hydraulic and power systems, along with SANY’s structural engineering, make it an ideal solution for mid-size heavy lifting tasks across industrial, infrastructure, and energy construction sites.
