Sumitomo SC350M

Engineered for multifaceted construction needs, the Sumitomo SC350M combines lifting proficiency with adaptable functionality. This 35-ton crawler crane features a robust main boom that extends to 42.5 meters and a jib length capable of reaching 33.5 meters with an additional 12.2-meter extension, providing considerable reach and versatility.

• Performance: The SC350M is fitted with a powerful Mitsubishi 6D14-T diesel engine, delivering 88.3 kW of power at 2,150 rpm, and 250 ℓ of fuel capacity, ensuring sustained operational capability.
• Lifting Capabilities: It is designed for various configurations, including a hook block, clamshell bucket, and dragline bucket, with respective lifting and digging capacities.
• Mobility and Stability: With a maximum travel speed of 1.7/1.0/0.6 km/h and a gradeability of 30%, this crane is mobile on diverse terrains, and the ground pressure of 50.9kPa (0.52kg/cm²) promotes stability.
• Efficiency: The crane offers swift operation with boom hoist and lower times of 3.8/2.5/1.3 min⁻¹, and winch speeds for hook, clamshell, and dragline operations to facilitate effective cycle times.
• Dimensions and Weight: The SC350M has a compact footprint, with different dimensions listed for its parts, and a total weight of 25,600 kg, ensuring ease of transportation and assembly.

The SC350M’s design emphasizes its ability to switch between roles as a crane, a clamshell digger, or a dragline, offering comprehensive solutions for digging, dredging, material handling, and lifting. The clamshell and dragline specifications highlight the crane’s flexibility, making it an indispensable asset in industries ranging from construction to mining and beyond. This crane is particularly suited for contractors and operators looking for a reliable, multi-use machine capable of performing in various challenging environments.
