XCMG XGC150-IA

Crawler Crane

The XCMG XGC150-IA is a highly optimized 150-ton crawler crane designed for efficiency in transport and complex lifting operations. It features an advanced design for easy assembly and disassembly, which significantly reduces setup times and transport costs. With a maximum boom length of 76 meters and an integrated system for versatile configurations, this crane offers robust performance and enhanced operational flexibility suitable for various construction environments.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

Optimized Design for Transport and Assembly

The XGC150-IA crane stands out for its highly efficient transport and assembly capabilities. The crane is designed with a modular approach where the tower jib and fixed jib can be segmented into three pieces for transport, maximizing the use of space and minimizing costs. The heaviest single transport unit stays under 29 tons, with a width not exceeding 3 meters, ensuring global transport compliance.

Structural and Mechanism Innovations

The superstructure of the XGC150-IA is a box-type design, prioritizing high load-bearing capacity while maintaining light weight for enhanced mobility. An auxiliary hoisting winch, strategically placed at the boom base, provides for relaxed maintenance and improved accessibility.

Performance Specifications

Maximum Lifting Capacity: 150 tons, with an operational range enhanced by a main boom that extends up to 76 meters.
Jib Configurations: Includes a 31-meter fixed jib with integrated configurations allowing for a variety of setup options to suit specific job requirements.
Engine and Power: The crane is powered by a 200 kW engine at 1800 rpm, meeting EURO III emissions standards, which underscores its commitment to environmental responsibility.
Hoisting Speeds: Features a dual winch system, capable of operating at 120 m/min for the main hoist and 90 m/min for the auxiliary, ensuring efficient load handling.

Enhanced Usability and Safety

Boom and Jib Angles: Offers a wide range of boom and jib angle adjustments, providing flexibility in lifting operations with boom luffing angles from -3 to 80 degrees and fixed jib angles from 15 to 30 degrees.
Travel and Swing: Maintains a maximum swing speed of 1.7 rpm and a travel speed of 1.3 km/h, balancing mobility and stability on site.

Cost-Efficiency and Environmental Considerations

The design reflects an acute awareness of the need for economic operation and environmental care, featuring a design that reduces the time and cost of transport and setup while complying with strict emission standards.

Overall, the XCMG XGC150-IA crawler crane is engineered to provide exceptional performance, ease of transport, and versatile setup options, making it a valuable asset for a wide range of heavy-lifting tasks in the construction industry.
