Zoomlion ZCC2000

Crawler Crane

The Zoomlion ZCC2000 is a 200-ton crawler crane, recognized for its dynamic capabilities and efficiency in substantial construction environments. It is especially suited for projects requiring significant lifting capacities and heights due to its extensive main boom and jib options.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

Performance and Lifting Capabilities

Maximum Lifting Capacity: Rated at 200 tons, providing formidable lifting power for a variety of construction needs.
Main Boom: Extends from 20 to 86 meters, enabling a broad range of lifting heights and reaches.
Luffing Jib: Length varies between 21 to 66 meters, increasing the crane’s ability to handle complex lifting scenarios where height and reach are crucial.
Fixed Jib: Stretches from 12 to 30 meters, used for lifts that require extended reach beyond the capacity of the main boom alone.

Operating Conditions

Tower Jib Work: Combining the tower jib and main boom can reach lengths of up to 125 meters (59 + 66 meters), optimizing the crane for exceptionally high lifts.
Hoisting Mechanism: The crane can achieve a maximum single rope speed of 143 m/min under fixed jib conditions, ensuring quick and efficient lifting operations.

Transportation and Setup

Transport Efficiency: Designed for easy disassembly and transportation, the crane’s components can be conveniently transported with a maximum single piece weight limit of 30 tons.
Grade Ability: The crane can operate on gradients up to 30%, showcasing its versatility in various site conditions.

Advanced Features and Usability

Control and Monitoring: Equipped with a wide control room, providing operators with a comprehensive view and enhanced control over the crane’s operations. Real-time monitoring of all electromechanical parameters is facilitated through an intuitive interface with easily accessible controls.
Safety Mechanisms: Features double or triple protection systems, including anti-tilting for the boom and misoperation prevention for enhanced operational safety.

Engine and Mobility

Engine Specs: Powered by a Cummins QSL9-C305 engine, it provides high performance with a rated power of 227 kW at 2000 rpm.
Walking Speed and Maneuverability: The crane has a maximum walking speed of 1.1 km/h and can operate efficiently on diverse terrains due to its robust track and chassis design.

This detailed configuration makes the Zoomlion ZCC2000 a highly reliable and versatile crane, suitable for intricate and heavy lifting tasks across various construction projects.
