Zoomlion ZCC2600V-2

The Zoomlion ZCC2600-2 is a purpose-built heavy-duty crawler crane designed to perform in mid-to-large scale lifting scenarios across industrial construction, infrastructure, and energy fields. Rated for a maximum lifting capacity of 260 tonnes at a 5-meter radius, it offers a strong lifting moment of 1,332 tonne-meters, positioning it as a highly capable machine in its class.

The crane’s main boom system reaches up to 86 meters in length, providing a wide operational range for vertical and long-radius lifts. It can be configured for either heavy-duty or light-duty lifting requirements, allowing the operator to tailor the boom profile to the specific load and site conditions.

For jobs requiring increased reach and overhead clearance, the crane can be equipped with a fixed jib of up to 30 meters, mounted on a main boom length between 30 to 84 meters. The fixed jib can be set at offset angles of 10°, 20°, or 30°, enabling precision load handling over obstacles or into tight working corridors.

The luffing jib system expands the crane’s vertical versatility, supporting a maximum jib length of 60 meters. The luffing jib can be combined with the main boom in two optimized configurations: 53 meters of main boom with 60 meters of luffing jib, or 59 meters of main boom paired with a 45-meter jib. These combinations are especially effective for high-rise structures, industrial tower segments, and installations requiring a steep lifting path with minimal ground footprint.

The ZCC2600-2’s winch systems are engineered for both power and speed. Hoisting winch 1 delivers rope speeds up to 120 meters/minute, while hoisting winch 2 offers up to 116 meters/minute, both measured at the sixth layer. The derricking winch operates at 2 × 48 meters/minute, ensuring responsive boom luffing performance. These winches allow for fast load cycles, essential in time-sensitive or repetitive lifting operations.

Slewing performance is equally refined, with a smooth rotation range of 0 to 1.8 rpm, enabling accurate positioning of loads even at extended radii. The crane travels on a crawler chassis with a speed of up to 1.0 km/h, and can handle slopes up to 30%, making it suitable for varied terrain. The undercarriage is fully retractable for transport efficiency, and the wide track base ensures operational stability during heavy lifts.

The ZCC2600-2 is powered by a Weichai WP10H336E62 engine, producing 247 kW at 1900 rpm, in compliance with China Stage VI emissions standards. This engine supports a load-sensing hydraulic system that enhances fuel efficiency and provides stable, responsive operation across all lifting and travel functions.

Transportability is a key strength of the ZCC2600-2. The heaviest transport component (main unit with mast and winch) weighs 44 tonnes, while other modules are optimized for efficient loading and road mobility. The full crane—including counterweights of 100 tonnes at the rear and 20 tonnes on the carbody—reaches an operational weight of approximately 235 tonnes depending on configuration.

The operator cabin includes ergonomic controls, climate control, and Zoomlion’s integrated monitoring system, which provides real-time feedback on critical metrics like load, radius, boom length, and wind conditions. Integrated safety features include a load moment indicator (LMI), anti-two-block system, over-hoisting protection, and auto-shutdown under unsafe parameters, ensuring safety and control on site.

In summary, the Zoomlion ZCC2600-2 crawler crane is a powerful, flexible lifting platform that adapts to complex and demanding lift environments. With a full suite of boom and jib combinations—including up to 86 meters of main boom and luffing jib configurations reaching 60 meters—it provides reliable and efficient lifting performance for large-scale projects while maintaining ease of transport and operational safety.
