XCMG QY30K5S

Hydraulic Truck Crane

The XCMG QY30K5S is a versatile 30-ton hydraulic truck crane designed for efficient and powerful lifting operations. It features a maximum load capacity of 30,000 kg and a comprehensive maximum boom length of 38.7 meters, extendable to 47.6 meters with the jib. With its robust engine and advanced hydraulic system, the QY30K5S delivers high performance in various construction environments, making it an essential tool for medium to large scale lifting tasks.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

Capacity and Dimensions

The XCMG QY30K5S boasts a significant lifting capacity of 30 tons and a maximum cargo torque of 1025 kN*m, providing strong lifting capabilities across a range of conditions. The crane’s overall dimensions are 12070 mm in length, 2500 mm in width, and 3290 mm in height, which allows for operation in tight spaces without compromising stability, thanks to its long lateral support span of 6850 mm and a transverse span of 6000 mm.

Performance Features

The crane’s fully extended boom reaches up to 38.7 meters, with an additional jib length that extends the total operational height to 47.6 meters. It is equipped with multiple boom angles (0°, 15°, 30°) to accommodate various lifting requirements. The crane offers a main winch lifting/lowering speed of 75 m/min when loaded, and an auxiliary winch speed of 120 m/min, ensuring quick and efficient load handling.

Engine and Mobility

Powered by a 6CL280-2 engine, the QY30K5S generates a rated power of 206 kW at 2200 rpm and provides substantial torque of 1170 Nm at 1400 rpm, facilitating strong performance under heavy loads. The crane’s maximum travel speed is 75 km/h, with a minimum operational speed of 2.9 km/h, allowing precise maneuvering and positioning on job sites.

Additional Operational Specifications

The minimum turning diameter of the crane is 11 meters, and it boasts a front suspension angle of 19 degrees and a rear overhang angle of 13 degrees, enhancing its ability to navigate difficult terrain. The crane also features a minimum road clearance of 291 mm, which, combined with its maximum gradeability of 30%, ensures it can operate effectively on uneven surfaces.

Efficiency and Safety

With fuel consumption at 40 liters per 100 km, the XCMG QY30K5S is designed for efficiency. Safety features include a braking distance of less than 10 meters at 30 km/h, ensuring quick and safe stopping power.

In summary, the XCMG QY30K5S truck crane is engineered to deliver powerful lifting capabilities and high operational efficiency, making it suitable for a wide range of lifting tasks in construction and industrial sectors.
