Zoomlion ZAT8000VS863

The Zoomlion ZAT8000VS863 is an advanced all-terrain crane with a lifting capacity of 800 tons, tailored for heavy-duty lifting tasks, such as wind turbine installation and other large-scale industrial applications. The crane’s main boom extends to 102.5 meters, enabling significant reach and lift heights.

The crane boasts a remarkable lifting moment of 17640 kN·m, with optimized lifting capabilities even at considerable boom lengths. It can lift up to 74 tons at a 56.4-meter radius, showcasing its powerful performance in demanding conditions. For taller structures, it can achieve a maximum lifting height of 146 meters with 12 tons, and up to 125 meters with a 93-ton tower assembly.

Designed with maneuverability in mind, the ZAT8000VS863 features a compact structure with a 20.5-meter long, 3-meter wide, and 4-meter high frame. It is equipped with a 7-axle chassis, allowing for a minimum turning radius of 25 meters and a ground clearance of 385 mm, which enhances mobility over rough terrain. The crane also supports six-wheel steering, optimizing its agility in tight spaces.

The ZAT8000VS863 is powered by a Euro VI-compliant OM473LA engine, delivering 480 kW of power at 1600 rpm. The engine’s performance supports a top driving speed of 80 km/h, ensuring efficient transportation between job sites. Additionally, the crane features a transmission system with a ZF12TT gearbox, enabling smooth power distribution across the axles for enhanced stability and traction.

Overall, the Zoomlion ZAT8000VS863 is a powerful and versatile all-terrain crane, offering superior lifting performance, mobility, and operational efficiency for heavy-duty construction and industrial projects.

More features includes:

• Counterweight Compatibility: The ZAT8000VS863 crane is designed to support a wide range of counterweight configurations, compatible with products across the 300-2400-ton crane series. This flexibility allows operators to adapt the counterweight setup according to the specific requirements of different lifting tasks, optimizing stability and lifting capacity for various projects.
• Jib and Tower Attachment Compatibility: The crane’s jib and tower configurations can be used with multiple series, specifically 500, 600, 650, and 800-series products. This indicates that the crane’s jib attachments are standardized to fit across these product lines, providing options for extended reach and higher lifting capabilities when necessary.
• Superlift Compatibility: The crane’s superlift system is compatible with the 240-900-ton crane series. A superlift enhances the crane’s lifting performance by providing additional counterweight and stability when lifting heavy loads at extended boom lengths. This compatibility ensures that the crane can be equipped with the right superlift system to meet the demands of various heavy lifting scenarios.
