Product Description
| Item | Unit | Data | |
|---|---|---|---|
| Max. lifting capacity | t | 650 | |
| Standard working condition | Heavy boom length | m | 24-84 |
| Light boom length | m | 66-102 | |
| Fixed Jib length | m | 12-36 | |
| Tower attachment length | m | 24-84 | |
| Standard superlift working | Heavy boom length | m | 36-96 |
| Light boom length | m | 90-138 | |
| Fixed Jib length | m | 12 | |
| Tower attachment length | m | 24-96 | |
| Max. single line hoisting speed( with no load,at 6th layer) | m/min | 130 | |
| Max. single line speed for boom elevating system(with no load,at 6th layer) | m/min | 58×2 | |
| Max. single line speed for tower attachment elevating system(with no load,at 6th layer) | m/min | 115 | |
| Max. single line speed for sideways superlift elevating system (with no load,at 6th layer ) | m/min | 115 | |
| Swing speed | r/min | 0.65 | |
| Propel speed | km/h | 1.0 | |
| Mean ground pressure | MPa | 0.146 | |
| Engine output | kW | 494 | |
| Total mass (with 650t hook block,24m heavy boom) | t | 530 | |
| Max. weight of single part(main machine) in transport state | t | 74 | |
| Dimension of single part(main machine) in transport state(L×W×H) | m | 12.6×3.4×3.4 | |
