Zoomlion ZCC2000-1

Crawler Crane

The Zoomlion ZCC2000-1 is a 200-ton crawler crane known for its adaptability and efficiency in heavy lifting operations. It features a modular design allowing for varied configurations with fixed and luffing jibs to meet diverse project needs.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

Overview of Configurations

Main Boom: Reaches from 20 meters up to 83 meters, providing substantial length for various lifting tasks.
Luffing Jib: Extends from 21 meters to 51 meters, complementing the main boom for increased reach and versatility.
Fixed Jib: Available from 13 meters to 31 meters, enhancing the crane’s utility in lift and carry operations.

Operating Modes and Features

S Mode: Utilizes just the main boom for standard lifting operations.
SH Mode: Features the goose head frame for specific lifting geometries, using the same boom length as the S mode.
SF-1, SF-2, SF-3 Modes: Incorporate the main boom with a fixed jib. The SF-1 and SF-3 modes involve auxiliary hooks, with or without the main hook, while SF-2 uses the main hook only.
SW Mode: Combines the main boom with a luffing jib for maximal height and reach flexibility.

Performance and Efficiency

Hoisting Speed: The maximum speed of the hoisting winch is 132m/min, which is among the highest in the industry, offering superior performance in speed-sensitive tasks.
Engine Power: Powered by a Weichai WP10G336E344 engine, delivering 247 kW at 1900 rpm, ensuring strong and reliable operations under heavy load conditions.

Safety and Comfort

Operator Environment: Boasts a 1.25m wide panoramic control room with a 10.4-inch color display and a high-definition camera, ensuring high visibility and control precision.
Advanced Controls: Features load feedback and a proportional hydraulic control system for smoother and more controlled movements.

Transportation and Maintenance

Ease of Transport: The crane can be disassembled into pieces with a maximum weight of 39 tons each, facilitating easier transport and setup.
Maintenance Features: Designed for ease of maintenance, featuring accessible parts and a systematic layout that reduces downtime and operational costs.

This configuration and feature set make the Zoomlion ZCC2000-1 a versatile choice for a range of construction environments, highlighting its ability to adapt to various lifting needs with high efficiency and safety.
