Tadano TT-600XL
The Tadano TT-600XL is a 60 US ton capacity rough terrain crane designed for high-performance lifting in off-road conditions. It features a long, five-section main boom, modern hydraulic systems, and compact carrier dimensions for superior mobility and setup efficiency in tight job sites.
⬇ DOWNLOADS ⬇
*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.
Advertisement
Product Description
The TT-600XL by Tadano represents a robust entry in the 60-ton rough terrain class, designed with both reach and lifting capacity in mind. The crane features a five-section full-power boom that extends from 35.1 feet (10.7 m) to a maximum of 141 feet (43 m), fabricated with high-tensile steel for durability and strength. For enhanced lifting height and versatility, the crane is also equipped with a bi-fold jib that ranges from 33.2 feet (10.1 m) to 58.1 feet (17.7 m), offering manual offsets at 0°, 20°, and 40°. Maximum tip height with jib reaches 199.5 feet (60.8 m), making it suitable for demanding lifts.
On the carrier side, the TT-600XL operates with a Cummins B6.7 diesel engine, compliant with EPA Tier 4 Final emissions standards, delivering 280 hp (209 kW) at 2,500 rpm. The transmission is a 6-speed automatic system allowing maximum traveling speeds of up to 24.8 mph (40 km/h). The unit’s 4×4 drive configuration and four-wheel steering with multiple steering modes (2-wheel, 4-wheel coordinated, crab, and rear steer) ensure excellent maneuverability on rough and uneven terrain.
The superstructure features an advanced hydraulic system with a tandem gear pump supplying a flow of 2 x 62 gal/min (2 x 235 l/min) and operating at 3,500 psi (245 bar). The dual winches offer high line pull at 18,200 lbs (82 kN) and line speeds up to 354 ft/min (108 m/min). Swing system performance is equally strong, with a planetary gear motor and a 360° swing range at 2.2 rpm, supported by a spring-applied hydraulic release disc brake.
For operational convenience, the TT-600XL is outfitted with Tadano’s AML-E2 load moment indicator and control system, color touch panel display, and Tadano View for blind-spot cameras. The operator’s cab is tilt-capable, with air conditioning and an adjustable seat for comfort during extended operation periods.
With a gross vehicle weight of 83,100 lbs (37,700 kg), the Tadano TT-600XL balances portability and power, built to support general construction, infrastructure, and industrial projects with consistent reliability and ease of use.
