Zoomlion ZTC250W562

The Zoomlion ZTC250W562 is designed to offer superior lifting capabilities, strong mobility, and enhanced operational efficiency, making it an industry-leading 25-ton truck crane.

Exceptional Lifting Performance

• Equipped with a five-section, 44.5-meter U-shaped main boom, the longest in its class, providing an excellent balance of strength and reach.
• The maximum lifting moment at the base boom is 1,336 kN·m, with a maximum lifting capacity of 8.1 tons at full boom extension.
• Uses an innovative high-strength boom structure, improving load-bearing capacity while maintaining stability.
• Features a 7.1-meter outrigger span, ensuring excellent stability during lifting operations.
• Wide load-bearing range enhances versatility and operational efficiency.

Powerful Chassis and Driving Performance

• Powered by an 8L low-speed, high-torque diesel engine, specifically designed for construction machinery, providing strong and stable power output.
• Features a Fast 8-speed synchronizer gearbox, ensuring smooth and efficient transmission.
• Uses rubber suspension and V-type thrust rod technology, enhancing lateral stability and providing a smoother driving experience.
• Equipped with soft-shaft shifting, making operation more comfortable and responsive.
• Achieves a top speed of over 80 km/h, with an impressive 45% gradeability, allowing for smooth transport even on steep inclines.

Smart and Efficient Operation

• Integrates a comprehensive onboard information system, enabling real-time operational monitoring and remote control accessibility.
• Features a 10.4-inch multifunctional intelligent display, providing precise load limit monitoring, winch monitoring, and virtual simulation functions.
• The maximum hoisting speed reaches 140 m/min, while the maximum lowering speed is 82.8 m/min, ensuring fast and efficient lifting operations.
• Offers ultra-low-speed winch operation, with a minimum hoisting speed of 2.5 m/min and a minimum slewing speed of 0.1°/min, ensuring precise load positioning.

Comfortable and Durable Design

• Features a green, eco-friendly, modern exterior coating, combining aesthetics with environmental consciousness.
• The 4.0m³ spacious cab provides an expanded driving space, an ergonomically designed seat, and an enhanced driver experience.
• Comes equipped with a 910mm widened side ladder for safe and convenient entry and exit.
• The hydraulic, electrical, and control systems are fully upgraded, ensuring greater reliability and longer lifespan.
• Includes user-friendly details such as all-angle cameras, anti-overturn fuel tank, and maintenance-free battery.

Eco-Friendly and Energy-Efficient

• Utilizes an energy-saving hydraulic system, reducing fuel consumption while maintaining high efficiency.
• The crane’s fuel consumption is as low as 30L per 100km, ensuring cost-effective operation.
