Zoomlion ZTC600R542

The Zoomlion ZTC600R542 is a high-performance 60-ton truck crane engineered for strength, efficiency, and reliability. It is equipped with a five-section U-shaped main boom, which extends from 11.6 meters to 45 meters, providing excellent structural integrity, high bending resistance, and reduced deflection. This ensures smooth lifting operations while maintaining high stability. Additionally, the crane includes a two-section foldable jib, offering offset angles of 0°, 15°, and 30°, increasing operational flexibility. The maximum lifting height reaches 45.5 meters with the main boom and 61 meters when using the jib, making it suitable for a wide range of lifting applications.

The ZTC600R542 features a high-performance winch system, where both the main and auxiliary winches are driven by axial plunger hydraulic motors with planetary gear reducers for smooth and efficient lifting. The main hoist rope has a diameter of 17mm, a strength grade of 1,870 N/mm², and extends up to 210 meters, while the auxiliary hoist rope extends 130 meters. The main hook has a 50-ton capacity, with six pulleys, a mounting lug, and a rotatable hook with a hook latch to ensure safe and stable load handling.

To provide smooth and controlled movements, the ZTC600R542 incorporates a load-sensing slewing system with a proportional main valve, allowing for precise micro-positioning and improved operational efficiency. The boom derricking time is 45 seconds, while the boom telescoping time is 100 seconds, ensuring quick deployment. The slewing speed ranges from 0 to 2.5 rpm, allowing for precise rotation during lifting operations.

The chassis of the ZTC600R542 is constructed from high-tensile steel, ensuring high durability and structural strength. It features a four-axle design, with the front two axles used for steering and the rear two for driving, providing excellent weight distribution and maneuverability. The crane is powered by a WEICHAI WP9H336E62 diesel engine, delivering 247 kW of power and 1,600 N·m of torque, ensuring high performance and fuel efficiency. It is paired with a FAST 10-speed mechanical gearbox (10 forward, 2 reverse gears), offering smooth gear transitions and efficient power delivery. The crane achieves a maximum driving speed of 48 km/h and a gradeability of 44%, allowing it to navigate various terrains with ease. The minimum turning diameter of ≤24 meters ensures better maneuverability, even in tight job sites.

For stability, the crane is equipped with H-type outriggers, providing an outrigger width of 7.4 meters (fully extended) and 4.88 meters (intermediate extension). The counterweight system includes a total of 6 tons, with a 5th outrigger overpressure protection device ensuring enhanced stability during lifting operations.

Operator comfort and safety are prioritized in the ZTC600R542. The spacious cab features an ergonomic layout, providing a comfortable operating environment with AC and heating for all-weather conditions. The electrical system operates on DC 24V with CAN BUS technology, offering advanced control and monitoring capabilities. Safety features include a hoisting limit switch, hook latch, two-way hydraulic lock, balance valve, and overflow valve, ensuring safe and efficient lifting operations.

With its powerful lifting capacity, robust chassis, advanced hydraulic systems, and operator-friendly design, the Zoomlion ZTC600R542 is an excellent choice for heavy lifting applications in construction, infrastructure, and industrial projects.
