Zoomlion ZTC800R532

Hydraulic Truck Crane

The Zoomlion ZTC800R532 hydraulic truck crane boasts a 47-meter “U” type boom with 5 sections, achieving a maximum lifting capacity of 11.5 tons. The crane is mounted on a 46-ton heavy-duty chassis capable of traveling at 50km/h with an 8t full counterweight. It features a Weichai WP10.375 engine paired with a Fast 10-speed gearbox for strong and efficient power transmission. The H-type double-stage movable outriggers provide excellent stability and environmental adaptability, and the crane is equipped with comprehensive safety devices to ensure operational security. It adheres to European Stage III emission standards and has a fuel consumption of 45L/Km.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

General Overview

The Zoomlion ZTC800R532 is a formidable hydraulic truck crane with high-capacity lifting abilities and advanced engineering designed to handle a wide range of construction needs.

Main Boom

The “U” type main boom extends up to 47 meters with 5 sections, allowing for a maximum lifting capacity of 11.5 tons. This design provides a balance between strength and flexibility, making it suitable for various lifting tasks.

Chassis and Performance

A 46-ton rated heavy-duty chassis supports the crane’s structure, and it can achieve speeds of up to 50km/h with an 8-ton full counterweight. This capability enhances the crane’s efficiency between job sites. The integration of a Weichai WP10.375 engine with a Fast 10-speed gearbox establishes a powerful and reliable drive system, ensuring the crane has sufficient power for all types of lifting operations.

Stability and Adaptability

With H-type double-stage movable outriggers and a maximum lateral span of 7.8 meters, the crane offers excellent stability and can adapt to a variety of environmental conditions.

Safety and Compliance

The ZTC800R532 features several safety devices, including wire rope over-discharge and outrigger over-pressure protection, to prevent accidents. Furthermore, the crane meets European Stage III emission standards and has CCC certification for its safety devices.

Fuel Efficiency

The crane’s fuel consumption stands at 45 liters per kilometer, a figure that reflects the crane’s power-to-efficiency ratio, tailored for heavy-duty applications while considering operational costs.

The Zoomlion ZTC800R532 combines substantial lifting capabilities with innovative design and engineering, making it a top choice for construction and industrial projects where efficiency, safety, and compliance are critical.
