Tadano GTC-800EX

The GTC-800EX, rebranded as the GTC-900 for global uniformity, exemplifies advanced engineering in mobile crane technology. It is designed to operate efficiently in challenging environments, equipped with a five-section full-power telescopic boom that extends from 11.5 meters to 43 meters.

Capabilities and Features

• Crane Capacity and Boom: The crane has an 80-ton capacity at a 3.0-meter radius, with a maximum lifting height of 42.1 meters. The boom’s design allows for quick reeving and precise load handling.
• Engine and Emissions: Powered by a Cummins B6.7 engine, the crane meets U.S. EPA Tier 4f and Euromot Stage V emission standards, highlighting Tadano’s commitment to reducing environmental impact.
• Mobility and Stability: The crawler tracks offer excellent stability and mobility, supporting operations in diverse terrain conditions with a gradeability of 78% and variable track width.

Advanced Technology Integration

• Safety Systems: Includes Tadano’s AML-C load moment indicator and anti-two-block system, ensuring operational safety by preventing overloading and block collisions.
• Operational Efficiency: Features a high-resolution LCD for monitoring crane operations, along with state-of-the-art controls for smooth functionality. The OPTI-WIDTH™ system optimizes lifting performance regardless of track width.

Dimensions and Transportability

• Compact Dimensions: In its transport configuration, the crane measures 14.00 meters in length, 5.32 meters in width (tracks extended), and 3.80 meters in overall height.
• Transportability: Designed for easy transport with disassemblable components and compact dimensions to meet road regulations.

Overall, the GTC-800EX/GTC-900 combines Tadano’s reliability and innovative technology to deliver superior lifting capabilities and operational safety, making it a prime choice for heavy lifting operations worldwide.
