Potain MDT 809

Flat Top, Tower Crane

Equipped with the new Crane Control System, the MDT 809 M25 provides greater performances. This user-friendly crane control system offers owners the highest levels of comfort, flexibility, ergonomic control – translating to a better return on investment. MDT CCS Topless concept allows complex multi-crane installations. The assembly, erection, transport and even maintenance phases are shortened. Optimum productivity and greater safety make MDT CCS cranes the best alternative for all users and hirers.

Additional Information

Max. Rated Capacity	25

Downloads

Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

thumbnail of MDT809_brochure_en — Brochure, EN

thumbnail of MDT809_flyer_en — Flyer, EN

thumbnail of MDT809M25_spec_lb_en_ASCE — Imperial, EN (ASCE)

thumbnail of MDT809M25_spec_mt_en_ENC25 — Metric, EN (ENC25)

thumbnail of MDT809M25_spec_mt_en_ENC50 — Metric, EN (ENC50)

thumbnail of MDT809M25_spec_mt_en_FEM — Metric, EN (FEM)

Product Description

Groundbreaking performances for a Topless

Specific design based on the Topless concept, with low space requirements to adapt to multi-crane job sites
High working heights obtained through newly developed installation bases and mast sections:
Integrated CCS control system

Optimized and economical transport

Compact size and limited weight of each of the crane elements
11 convoys at the most for transportation of the whole slewing crane part with an 80 m jib.

Fastest 40 t tower crane assembly

Simple and rapid unfolding of the ballast cage
Wired tower head/cab assembly fitted just once (no intersite dismantling)
Cathead/jib foot is a single element
Modular jib without tie bars: several configurations are possible; lighter package weights with quick and easy handling
Cross-shaped base comprised of a main girder and 2 half cross-girders connected easily using pins
Quick and easy commissioning, adjustment of safety devices done in the cab on the CCS screen
