Grove GMK5210

Mobile Crane

The Grove GMK5210 is a 210 US ton all-terrain crane equipped with a versatile six-section, full-power boom that extends from 44 feet to 197 feet. It features advanced engineering, such as a patented “twin-lock” boom pinning system, and is capable of reaching a maximum tip height of 207 feet with additional lattice extensions. Designed for robust and efficient performance, this crane excels in challenging environments and diverse lifting tasks.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

The GMK5210 is an all-terrain hydraulic crane with a substantial lifting capacity of 210 US tons, making it ideal for heavy-duty tasks in various settings, including construction and industrial projects.

Main Boom and Jib Configurations

This model features a 197-foot (60 meters) six-section, full-power boom. The boom incorporates Grove’s patented “twin-lock” system for securing boom sections, ensuring safety and stability during operations. The crane also includes a lattice swingaway extension that can be hydraulically offset between 5 to 40 degrees, with additional extensions available to reach a total length of up to 125 feet (38 meters).

Engine and Performance

The crane is equipped with a powerful Cummins Signature 600 engine, offering 600 HP at 2000 rpm and a maximum torque of 2,050 ft./lbs. at a range of 1200-1400 rpm. It complies with EUROMOT/EPA/CARB emission standards, ensuring environmentally responsible operations. The crane’s maximum travel speed is 51 mph, and it features a gradeability of 55%, suitable for steep inclines.

Slewing and Lifting Capabilities

The GMK5210 offers a slewing speed of up to 1.7 RPM, provided by three swing gears with axial piston fixed displacement motors. The crane’s maximum lifting speed is 426 ft./min with a line pull capacity of 21,000 lbs., allowing for efficient handling of heavy loads.

Mobility and Chassis Configuration

This model boasts a 10x8x10 drive configuration, ensuring excellent mobility on various terrains. It is designed with a robust chassis that supports the crane’s versatile operations in diverse environments. The suspension system is the Grove-exclusive MEGATRAK suspension, which adjusts both longitudinally and transversely to maintain optimum leveling and stability.

Additional Features

The GMK5210 includes advanced safety features like a load moment and anti-two block system with audio and visual warnings, enhancing operational safety. The cab is constructed from aluminum with adjustable operator’s seating and ergonomic controls, ensuring operator comfort and ease of use during long hours of operation.
