Zoomlion ZCC800H

Features:

• Capacity and Reach: The ZCC800H shines in its lifting capability, supporting up to 7 tons with the fixed jib and 15 tons with the luffing jib, facilitating a range of lifting tasks from construction to infrastructure development.
• Boom and Jib: Its main boom spans a length of 13-58 meters paired with a fixed jib ranging from 6-18 meters and a luffing jib of 16-34 meters, providing the flexibility needed for complex lifting scenarios.
• Engine Performance: A powerful Weichai WP10.270N engine rated at 199 kW ensures reliable and efficient crane operations, backed by a notable maximum torque of 1270 Nm for robust performance.
• Operational Efficiency: With a hoisting speed of up to 125 m/min and a slewing speed of 0-2 rpm, the crane operates with precision and quickness, enhancing job site productivity.
• Maneuverability: It offers a traveling speed of up to 1.57 km/h and can tackle gradients up to 30%, showcasing its capability to navigate through challenging terrains.
• Stability and Ground Pressure: The crane maintains a ground pressure of just 0.083 MPa, ensuring stability during lifting without exerting excessive force on the ground surface.
• Counterweight and Dimensions: With a counterweight of 27 tons and overall dimensions of 13500×5000(3400)x3200 mm, the ZCC800H maintains a compact footprint while delivering powerful lifting solutions.
• Environmental Compliance: The engine meets National Stage III exhaust emissions standards, reflecting Zoomlion’s commitment to environmental responsibility alongside performance.

The Zoomlion ZCC800H stands out as a reliable and efficient crawler crane, well-suited for a wide range of lifting applications. Its combination of power, precision, and adaptability makes it a valuable asset to any project demanding high-performance lifting solutions.
