Sany STC160C

Hydraulic Truck Crane

The Sany STC160C is a robust 16-ton hydraulic truck crane designed for high efficiency and stability in various lifting operations. It features a 4-section U-shaped boom that extends up to 30 meters, providing a maximum lifting height of 30.5 meters. Equipped with a 162 kW engine and an 8-gear gearbox, the STC160C combines excellent mobility with advanced safety and operational features, making it an ideal choice for a wide range of industrial and construction applications.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

Capacity and Performance

The STC160C truck crane offers a maximum lifting capacity of 16 tons, with a comprehensive maximum boom length of 32 meters, extending further with a jib to 40 meters. This crane’s maximum lifting moment reaches 730 kN.m, showcasing its considerable strength for various lifting tasks. It also features an impressive outrigger span of 5.8×4.98 meters, ensuring excellent stability during operations.

Engine and Mobility

The crane is powered by an SDEC SC7H245Q4 engine, which produces a rated power of 180 kW at 2300 rpm and a maximum torque output of 960 N.m at 1400 rpm. This power allows the crane to reach a maximum speed of 80 km/h and handle gradients up to 40%, demonstrating substantial mobility and flexibility on diverse site conditions.

Structural and Safety Features

The STC160C is equipped with a range of safety and operational enhancements, including a high-precision, high-stability moment limiter and a comprehensive safety system that provides real-time monitoring of working conditions. The crane’s chassis includes a full-width driving cab with a sleeper, ergonomically designed to enhance operator comfort and safety.

Operating Conditions

The crane operates effectively with minimum turning radii of 10.5 meters and maintains a minimum ground clearance of 260 mm, suitable for various ground conditions. It also boasts a fuel-efficient performance with a consumption rate of 28 liters per 100 km.

Additional Features

Other notable features include a high-strength structural steel construction for the telescopic boom and an advanced hydraulic system for smooth operations during slewing, extending, and retracting phases. The truck crane also comes with a sleeper cab, adding comfort for operators during extended operations.

In summary, the Sany STC160C truck crane combines advanced engineering, significant lifting capacity, and extensive safety features to deliver superior performance and reliability in demanding lifting operations.
