Zoomlion ZMC60

Hydraulic Truck Crane

The Zoomlion ZMC60 is a 60-ton hydraulic truck crane, designed for superior lifting capacity, enhanced mobility, and optimal operational efficiency. It features a five-section telescopic boom, extending from 11.4 meters to 48.3 meters, and a two-section jib (9.5m and 16m) with offset angles of 0°, 15°, and 30°, achieving a maximum lifting height of 59.5 meters. The maximum lifting moment is 1,960 kN·m, providing strong performance across a range of lifting applications. Equipped with a high-performance diesel engine, the crane reaches a top speed of 80 km/h and a gradeability of 40%. With an advanced hydraulic control system, intelligent safety features, and a compact 4-axle chassis, the ZMC60 is an ideal solution for construction, infrastructure, and industrial lifting operations.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

The Zoomlion ZMC60 is a high-performance 60-ton truck-mounted hydraulic crane, built for exceptional lifting capacity, superior mobility, and efficient control. It features a five-section telescopic main boom, made of high-strength steel, extending from 11.4 meters to 48.3 meters, ensuring strong load-bearing capacity and reduced deflection. The two-section jib (9.5m and 16m) with adjustable offsets of 0°, 15°, and 30° allows for increased operational flexibility, reaching a maximum lifting height of 59.5 meters. With a maximum lifting moment of 1,960 kN·m, the ZMC60 delivers strong lifting performance for a variety of heavy-duty tasks.

The crane is powered by a high-efficiency diesel engine, ensuring reliable performance and optimized fuel consumption. It can reach a maximum driving speed of 80 km/h, with a gradeability of 40%, allowing it to navigate various terrains with ease. The minimum turning diameter of 24 meters enhances maneuverability, even in confined workspaces.

For lifting efficiency, the ZMC60 is equipped with dual winches, providing a hoist rope speed of 120 m/min (main and auxiliary winches), ensuring fast and precise lifting. The boom derricking time is 50 seconds, while boom telescoping takes 95 seconds, allowing for rapid setup and operation. The slewing system, with a slewing speed of 2.0 rpm, ensures smooth and accurate load positioning.

The chassis is built for stability and durability, featuring a 4-axle configuration with all-wheel steering, providing better maneuverability and flexibility. The H-type outrigger system offers a fully extended transversal width of 7.1 meters and a longitudinal extension of 5.92 meters, ensuring stability during lifting operations.

Operator comfort and safety are key priorities in the ZMC60. The spacious cab is ergonomically designed, featuring air conditioning, an adjustable seat, and an intuitive control interface, providing a comfortable and user-friendly working environment. The crane is equipped with an advanced hydraulic control system, utilizing a load-sensing directional valve system, ensuring smooth and efficient movement coordination.

Safety features include a load moment indicator (LMI), relief valves, balance valves, and emergency stop functions, ensuring secure and stable operations. The special tire configuration offers optimal road and off-road driving conditions, making the ZMC60 suitable for a variety of working environments.
