Zoomlion ZTC1500V

Hydraulic Truck Crane

The Zoomlion ZTC1500V is a high-performance 150-ton hydraulic truck crane, designed for superior lifting capacity, precise control, and enhanced safety features. It features a seven-section telescopic main boom, extending up to 72 meters, and a jib extension, reaching a total lifting height of 87 meters, with an additional extension jib increasing the lifting height to 95 meters. The crane has a maximum lifting moment of 4,705 kN·m, making it one of the strongest in its class. It is powered by a high-efficiency diesel engine, ensuring excellent mobility with a top speed of 80 km/h and a gradeability of 42%. The ZTC1500V integrates advanced electro-hydraulic proportional control, load-sensing slewing, and multiple safety features, making it ideal for heavy-duty lifting applications in construction, infrastructure, and industrial projects.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

The Zoomlion ZTC1500V is a state-of-the-art 150-ton truck-mounted hydraulic crane, engineered to provide unmatched lifting capacity, advanced control precision, and superior operational safety. The crane is equipped with a seven-section telescopic boom, which extends from 13.5 meters to 72 meters, offering exceptional reach and structural stability. Additionally, it includes a jib extension (11m and 18.6m), bringing the total lifting height to 87 meters, with an optional extension jib increasing it to 95 meters. This allows the crane to handle a wide range of heavy-lifting tasks in demanding environments.

The ZTC1500V is powered by a high-performance diesel engine, delivering strong torque and efficient fuel consumption, ensuring powerful and reliable operation. The drivetrain system enables a maximum driving speed of 80 km/h, with a gradeability of 42%, making it highly adaptable to various terrains and construction sites. With a minimum turning diameter of 423 mm, the crane offers impressive maneuverability for a machine of its size.

For lifting efficiency, the ZTC1500V is equipped with high-speed dual winches, providing a hoist rope speed of 116 m/min (main winch) and 86 m/min (auxiliary winch), ensuring fast and precise lifting. The boom derricking time is 36 seconds, while boom telescoping takes 160 seconds, allowing for quick setup and efficient operation. The slewing system, with a slewing speed of 1.6 rpm, features load-sensing technology, ensuring smooth and precise load positioning.

The ZTC1500V is designed for maximum stability, featuring a heavy-duty 5-axle chassis with a fully extended outrigger spread of 7.8 meters and an intermediate extension of 5.3 meters, providing a solid foundation for lifting operations. The overall vehicle dimensions (15,600 × 3,000 × 3,950 mm) allow for efficient transportation and deployment.

The operator’s cab is ergonomically designed with a spacious layout, air conditioning, and an intuitive control panel, offering a comfortable and efficient working environment. The crane is equipped with advanced electro-hydraulic proportional control, utilizing a load-sensing directional valve system, which ensures optimized movement efficiency and energy savings.

Safety is a priority in the ZTC1500V, with built-in relief valves, balance valves, and electronically controlled safety devices, ensuring stable and secure operations. The emission and safety systems comply with GB3847-2005 and GB17691-2005 standards, ensuring environmental efficiency and operator protection.
