Zoomlion ZTC800V532 Load Chart PDF + Specifications

The Zoomlion ZTC800V532 is an advanced 80-ton hydraulic truck crane designed for high efficiency, powerful lifting performance, and superior mobility. It features a five-section U-shaped main boom, which extends from 12.1 meters to 47 meters, providing exceptional bending resistance and load-bearing capacity. Additionally, the two-section jib (9.5m & 16m) offers offset angles of 0°, 15°, and 30°, allowing for greater reach and flexibility. With a maximum lifting moment of 2,646 kN·m and a maximum lifting height of 63.8 meters, this crane is suitable for heavy lifting operations in construction, energy, and infrastructure projects.

For precise and smooth lifting, the ZTC800V532 is equipped with a high-efficiency winch system, featuring a main hoist rope speed of 125 m/min (4th layer) and an auxiliary hoist rope speed of 110 m/min (2nd layer). The boom derricking time is 55 seconds, while boom telescoping is completed in 120 seconds, ensuring quick and efficient deployment. The slewing system integrates an innovative load-sensing technology with a proportional main valve, providing better micro-positioning with a minimum stable slewing speed of 0.1°/s.

The chassis and drivetrain of the ZTC800V532 are built for robust performance and durability. It features a high-strength steel chassis with reinforced axles and a heavy-duty suspension system, ensuring stability and durability under heavy loads. The crane is powered by a high-torque engine, allowing for a maximum driving speed of 85 km/h and an impressive gradeability of 46%, making it capable of handling various terrains with ease. The minimum turning diameter of ≤24 meters further enhances its maneuverability.

To enhance fuel efficiency, the ZTC800V532 incorporates an intelligent multi-power mode energy-saving system, which reduces fuel consumption to 4.5L per hour, leading to up to 20% savings in fuel costs. The hydraulic system features an independent radiator, ensuring optimal temperature control (below 75°C) for extended operational longevity.

Operator comfort and safety are key priorities in the ZTC800V532. The driver’s cab is ergonomically designed with a modern and spacious layout, equipped with air conditioning and a fully tiltable operator’s seat for better visibility and control. The electrical system operates on a DC 24V system, ensuring reliable power distribution for crane functions. Safety features include a hoisting limit switch, hook latch, hydraulic locks, a balance valve, and an overflow valve, all designed to enhance operational security.

With its powerful lifting capacity, innovative hydraulic and slewing systems, robust drivetrain, and energy-efficient design, the Zoomlion ZTC800V532 is an ideal solution for demanding lifting operations, providing a balance of strength, precision, and efficiency for modern construction and industrial applications.
