Tadano GR-250N-3

Rough Terrain Crane

The Tadano GR250N-3 is a 25-ton capacity rough terrain crane, designed for efficient urban operation with a 4-section hydraulic boom and a 2-section power tilt jib. Engineered for both performance and mobility, it comes with X-type or H-type outrigger configurations and is compliant with Japan’s “Basic running conditions” vehicle certificate system.

⬇ DOWNLOADS ⬇

Available Downloads:

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Product Description

The Tadano GR250N-3 is a compact and powerful 25-ton rough terrain crane that delivers versatility and maneuverability for a wide range of lifting operations, particularly in urban environments and constrained job sites. With the ability to be configured with either X-type or H-type outriggers, the crane is built to adapt to varied working conditions while maintaining Tadano’s signature lifting performance.

This model features a 4-section main boom that offers a balance between reach and strength, making it suitable for both medium- and light-duty lifts. For additional operational flexibility, the GR250N-3 is equipped with a 2-section power tilt jib, allowing for extended reach and a range of jib working angles. This jib setup improves its ability to perform lifts over obstacles or in elevated working positions.

In terms of dimensions, the GR250N-3 measures approximately 11,530 mm in overall length, with a wheelbase of 5,440 mm. The overall width is 2,620 mm, and it stands at a height of about 3,495 mm. These compact dimensions allow it to navigate narrow urban spaces while still providing solid lifting power.

The crane has been developed with attention to transportation and road regulation compliance in Japan. It has received the “Basic running conditions – weight: A” certificate of conformance under the country’s Newly Developed Vehicle Certificate System. However, actual running conditions are determined based on specific route calculations by the local road administrator.

Tadano has also emphasized operator safety and convenience in the GR250N-3. Optional features like the AML (Automatic Moment Limiter) external warning lamp, rear monitor camera, marker lamp, and road shoulder lamp can be added to improve visibility and operational safety.

Overall, the GR250N-3 continues Tadano’s tradition of combining performance, safety, and ease of use in a rugged, compact design. It’s an excellent choice for lifting tasks in tight areas or on jobs requiring both travel and lift performance with minimal logistical hassle.
