Tadano TR350M-3

The TR-350M-3 features a hexagonal boom structure that offers excellent strength and smooth extension, reaching up to 36.3 meters. With the hydraulic jib extension, the crane’s lifting height increases to 50.1 meters, and the jib offset can be adjusted hydraulically from 5° to 45°. This flexibility makes it ideal for multi-angle lifting tasks.

Its main and auxiliary winches offer hoisting speeds of up to 126 m/min, supported by a 16 mm wire rope, and the slewing system delivers 360° continuous rotation at 2.3 rpm. Boom elevation ranges from 0° to 83° in just 53 seconds, ensuring efficient lifting cycles.

The crane is powered by a Mitsubishi 6D24-TE1 turbocharged diesel engine that produces 290 PS (213 kW) at 2,200 rpm during travel, and 215 PS (158 kW) at 1,410 rpm during lifting. It supports both 2WD and 4WD drive modes, has a top speed of 49 km/h, and offers excellent gradeability of up to 57%.

Suspension is hydro-pneumatic with axle lock capability, and the steering system includes 2WS and 4WS modes. The crane’s minimum turning radius is just 5.2 meters with 4-wheel steering, enhancing maneuverability in confined sites.

The TR-350M-3 comes with fully hydraulic X-type outriggers that can be adjusted to several working widths, up to 6.7 meters. Safety features include Tadano’s AML (Automatic Moment Limiter), drum locks, anti-two block, and multiple hydraulic safety valves.

Inside the cab, the operator benefits from a tilt-adjustable seat, full instrumentation, air conditioning, and a multi-function AML monitor. These features, combined with its compact dimensions and reliable performance, make the TR-350M-3 an excellent choice for mid-size lifting operations in urban or off-road environments.
